Installation Guide

Installing\Replacing the Solar LED Bulb (Fig. 2 / Fig. 3)
The Solar LED Bulb is designed to last up to 10 years, however if it doesn’t work, or
if you want to use different color temperature bulb, it can be easily replaced.
1. Detach the top of the lamp unit (E) by releasing the 2 screws. Make
sure the Low/OFF/High switch is in the OFF (O) position.
2. Remove (if needed) the existing bulb by turning it counterclockwise.
3. Install the new Solar LED Bulb by turning into the bulb socket
clockwise.
4. Reassemble the unit by reversing the above procedure
Operation Instructions (Fig. 4)
Turn the Low/Off/High switch located on the lamp head (E) to Low or High position
according your preferences
Fig. 3
Fig. 3
Fig. 2
Fig. 4
Fig. 5
