GS-94B-F GS-94B-P GS-94B-W

Introduction

Thank you for your purchase. GAMA SONIC® solar charged lighting eliminates the

problems associated with most solar lighting available today. GAMA SONIC® solar

charged lights are brighter and last all night with a typical solar charge. Unique

design, superior light output and numerous installation options confirm the

outstanding value of our product.

GAMA SONIC® has been recognized as a worldwide leader in the lighting industry for

over 20 years. The company also offers unique products from multi-purpose solar

lamps to emergency lighting products.

For technical assistance and more information call our Toll Free number:

800-835-4113 (only within the US) or visit our website at: www.gamasonic.com.

Please read the instruction manual carefully to obtain the best results from your

purchase.

Tools that are needed but not supplied with the solar post lamps are: a screw driver

and a power drill.

Solar Lamp Location:

For optimum light duration throughout the night, it is very important to place the solar

panel in a spot where it will receive the maximum amount of direct sunlight

throughout the day. Also, for best results install your solar panel facing the south.

VICTORIAN SOLAR LAMP

With Solar LED Bulb

US Patent # 7172307

US Patent Pending # 14301356

Instruction Manual

Model: GS-94B-FPW

Summary of content (4 pages)

PAGE 1
VICTORIAN SOLAR LAMP With Solar LED Bulb US Patent # 7172307 US Patent Pending # 14301356 Instruction Manual Model: GS-94B-FPW GS-94B-F GS-94B-P GS-94B-W Introduction Thank you for your purchase. GAMA SONIC® solar charged lighting eliminates the problems associated with most solar lighting available today. GAMA SONIC® solar charged lights are brighter and last all night with a typical solar charge.
PAGE 2
Assembly instructions (Fig. 1) Fig. 1 NOTE: The following steps are for reference only. Consult your local hardware store for the best installation method for your particular surface. GS-94P (Post Mount) 1. Use an electric drill to make four holes in the desired surface. Place provided anchors into holes, place the base of the lamp (C) in line with the holes and attach with the provided screws. 2. Screw part (A) into Part (C). GS-94W (Wall Mount) 1.
PAGE 3
Installing\Replacing the Solar LED Bulb (Fig. 2 / Fig. 3) The Solar LED Bulb is designed to last up to 10 years, however if it doesn’t work, or if you want to use different color temperature bulb, it can be easily replaced. 1. Detach the top of the lamp unit (E) by releasing the 2 screws. Make sure the Low/OFF/High switch is in the OFF (O) position. 2. Remove (if needed) the existing bulb by turning it counterclockwise. 3. Install the new Solar LED Bulb by turning into the bulb socket clockwise. 4.
PAGE 4
Replacing the Batteries (Fig. 2 / Fig. 5) (After several years of use, the battery may need replacing). 1. Detach the top of the lamp unit (E) by releasing the 2 screws. Make sure the Low/OFF/High switch is in the OFF (O) position. 2. Unscrew the battery compartment screw. 3. Unclip the connector and remove the old battery. Make sure the new battery is high quality 3.2V/3000mAh Li-Ion rechargeable battery with connector. 4.
