3E4291 Gallagher T20 Terminal Installaon Note | Edion 1 | August 2016

Facia

Fit T10 Torx Post screw to

secure facia to bezel

Building cable

Terminal tail

Connecon

Bezel

9. Removal of the facia assembly is a simple reversal of these steps.

10. Congure the terminal in Command Centre. If the terminal is connected as an HBUS device,

refer to the topic "Conguring an HBUS Terminal", "Conguring an HBUS Alarms Only Terminal"

or "Conguring the PIV Card Reader" in the Command Centre Conguraon Client Online Help.

If the terminal is connected as a Cardax IV device, refer to the topic "Creang Readers" in the

Command Centre Conguraon Client Online Help.

5 LEDindicaons

LED (squiggle) HBUSindicaon

3 Flash (Amber) No communicaons with the Controller.

The terminal screen displays the text 'Connecng...'.

2 Flash (Amber) Communicaons with the Controller, but terminal is not congured. The

terminal screen displays the text 'Not congured'.

1 Flash (Amber) Congured to a Controller, but terminal is not assigned to a door or elevator

car. Congured to a Controller but the Alarms Terminal has no Alarm Zone(s)

assigned to the Alarms Zones property page.

The terminal screen displays the text 'Not congured'.

On (Green or Red) Fully congured and funconing normally.

If assigned to a door or elevator car:

Green = Access mode is Free

Red = Access mode is Secure

For the Alarms Terminal the LED is green when a user is logged on and red

when logged o.
