Bezel
6-32 (32 mm) screw
M3.5 (40 mm) screw
4. Drill pilot holes for the four corner xing holes and the tamper tab. Secure the bezel to the
mounng surface using the four corner xing screws provided. Secure the tamper tab (located
in the bezel) to the mounng surface using the remaining xing screw provided. It is important
the four corner xing screws are used to ensure the reader is ush with and ght against the
mounng surface.
Note: It is strongly recommended that you use the screws provided. If an alternave screw is
used, the head must be no larger nor deeper than that of the screw provided.
No. 6 pan
head screw
Bezel
Building cable
Tamper tab
Connect building
cable to terminal
block
