4 Installaon
ATTENTION: This equipment contains components that can be damaged by
electrostac discharge. Ensure both you and the equipment are earthed before
beginning any servicing.
The Gallagher T21 PIV Reader can be mounted on:
• a vercal, rectangular 50 mm x 75 mm (2 in x 3 in) ush box
• a BS 4662 Brish Standard square ush box
• any solid at surface
The recommended mounng height for the reader is 1.1 m (3.6 ) from the oor level to the centre
of the reader. However this may vary in some countries and you should check local regulaons for
variaons to this height.
Notes:
• Consideraon should be given to the installaon environment when using Gallagher mobile
credenals, as the Bluetooth® wireless technology read range may be reduced.
• Installaon on metal surfaces, parcularly those with a large surface area will reduce read range.
The extent to which the range is reduced will depend upon the type of metal surface.
• When mounng on a ush box, the corner screws must be used as well as the ush box screws.
Without corner screws the top of the product is vulnerable to separaon from the wall.
1. Ensure the building cable has been run out through the ush box.
If you are not mounng to a ush box, use the reader bezel as a guide, to drill all ve holes. Drill
the 13 mm (1/2 inch) diameter centre hole (this is the centre hole for which the building cable
will exit the mounng surface) and the four corner xing holes. Ensure the centre hole allows
the cable to run freely out through the mounng surface, so that the reader facia can clip into
the bezel.
Note: There is no room for the building cable to be squeezed into the reader bezel. The building
cable must remain within the ush box or wall cavity.
2. Run the building cable through the reader bezel.
3. Secure the bezel to the ush box using the two screws provided.
When securing the bezel to a vercal, rectangular ush box, use the 6-32 UNC screws provided.
When securing the bezel to a BS 4662 Brish Standard square ush box, use the M3.5 screws
provided.
