Fit security screw to
secure facia to bezel
9. Removal of the facia assembly is a simple reversal of these steps.
Hint: Aer removal of the security screw, press the top of the facia. The boom of the facia will
exit the reader bezel. Alternavely, carefully use an electrical screwdriver to lever the boom of
the facia away from the bezel.
10. Congure the reader in Command Centre. Refer to the topic "Conguring an HBUS Contact Card
Reader" in the Command Centre Conguraon Client Online Help.
11. The reader's contact card slot is rated for 100,000 card inserons. Should the reader's contact
card slot become blocked or wear over me, a replacement bezel including the contact card
reader (C305280 or C305281) can be purchased.
5 Screen brightness
When the reader is in use the screen brightness will be set to full. If the reader hasn't been used for 30
seconds, the screen brightness is dimmed. If the reader hasn't been used for 30 minutes, the screen is
turned o.
Note: The reader screen can be set to on at all mes ('Always on' seng enabled on the HBUS Contact
Card Reader item's property page in Command Centre). If this seng is enabled, the reader's screen
will not turn o aer 30 minutes, but will dim aer 30 seconds of inacvity.
