PARTS LIST

7-9

Part No. 001-3474-002

EP 200 MINI CER CRY PIN INSUL 010-0345-280

J 201 14P SGL ROW RCPT.1CNTR 615-7110-214

J 501 STR TERM PCB 615-3013-030

L 222 1+/-6%UH VAR. IND. 5MM 642-1012-015

L 224 1+/-6%UH VAR. IND. 5MM 642-1012-015

MP 801 CAN-VCO 3474 017-2225-751

MP 802 TOP SHIELD 3474 XMIT 017-2225-761

MP 803 SHIELD 3474 BOTTOM XMIT 017-2225-762

MP 804 3474 SHIELD BOTTOM SYNTH 017-2225-763

MP 806 XTAL FLTR SHIELD 3472 017-2225-699

R 230 2.7K OHM J 063W 0603 CHIP 669-0155-272

R 261 200k OHMS J 063W 0603 CHI 669-0155-204

RE 000 SCHEMATIC DL 3474 MAIN 025-3474-030

RE 000 ASSEMBLY DL 3474 MAIN BD 027-3474-030

Y 801 17.5 MHZ TCXO +/-1.5 PPM 618-7009-521

Z 221 52.95MHZ 4P 8KHZ BW 632-0009-011

Z 241 450 KHZ, 9 KHZ BW CERAMIC 632-2004-015

Z 242 450 KHZ, 9 KHZ BW CERAMIC 632-2004-015

023-3474-521

C 225 39pF 5% NPO 0603 610-3674-390

C 227 10pF +/-.1pF NPO 0603 610-3673-100

EP 200 MINI CER CRY PIN INSUL 010-0345-280

J 201 14P SGL ROW RCPT.1CNTR 615-7110-214

J 501 STR TERM PCB 615-3013-030

L 222 1+/-6%UH VAR. IND. 5MM 642-1012-015

L 224 1+/-6%UH VAR. IND. 5MM 642-1012-015

MP 801 CAN-VCO 3474 017-2225-751

MP 802 TOP SHIELD 3474 XMIT 017-2225-761

MP 803 SHIELD 3474 BOTTOM XMIT 017-2225-762

MP 804 3474 SHIELD BOTTOM SYNTH 017-2225-763

MP 806 XTAL FLTR SHIELD 3472 017-2225-699

R 230 1.8K OHMS J 063W 0603 CHI 669-0155-182

R 261 120K OHM J 063W 0603 CHIP 669-0155-124

RE 000 SCHEMATIC DL 3474 MAIN 025-3474-030

RE 000 ASSEMBLY DL 3474 MAIN BD 027-3474-030

Y 801 17.5 MHZ TCXO +/-1.5 PPM 618-7009-521

Z 221 52.95MHZ 4P 15KHZ BW 632-0009-009

Z 241 CERAMIC DATA FILTER 450KH 632-2004-016

Z 242 CERAMIC DATA FILTER 450KH 632-2004-016

023-3474-531

C 225 39pF 5% NPO 0603 610-3674-390
