Service Manual

GENERAL INFORMATION
1-6
Part No. 001-3474-002
Duty Cycle 50%, 60 seconds maximum transmit
Transmitter Attack Time < 7 ms (dependent on synthesizer implementation)
Spurious and Harmonic FM -37 dBm
FM Hum and Noise -40 dB 12.5 kHz, -45 dB 25 kHz
Audio Response ±1.5 dB from DC to 5 kHz (reference to 1 kHz)
Programmable to ±1 dB at the RF band edges via J201, pin 14.
Data Input Impedance 100k ohm
Modulation Response ±1 dB from DC to 5 kHz (reference to 1 kHz)
Current Drain < 800 mA at 2W, +7.5V DC
