Spec Sheet

RC 462 704
fully integrated
Width 24" (61 cm)
RC 472 704
fully integrated
Width 30" (76.2 cm)
RC 492 704
fully integrated
Width 36" (91.4 cm)
Included accessories
1 egg holder with lid
Installation accessories
RA 421 615
Stainless steel door panel with handle
For 24" (61 cm) wide appliances,
panel thickness ¾".
RA 421 713
Stainless steel door panel with handle
For 30" (76.2 cm) wide appliances,
panel thickness ¾".
RA 421 914
Stainless steel door panel with handle
For 36" (91.4 cm) wide appliances,
panel thickness ¾".
RA 423 140
Side trims, long.
RA 425 110
Short stainless steel handle for
freezer drawer, length 25 ⅞", with two
brackets, drilling distance between the
mounts 25 ¹⁄₁₆".
RA 428 615
Stainless steel door panel, handleless
For 24" (61 cm) wide appliances, panel
thickness ¾".
RA 428 713
Stainless steel door panel, handleless
For 30" (76.2 cm) wide appliances,
panel thickness ¾".
RA 428 914
Stainless steel door panel, handleless
For 36" (91.4 cm) wide appliances,
panel thickness ¾".
RA 460 000
Installation kit for side-by-side installation
(for connecting any two columns)
Side-by-side kit comes already
attached to all RF freezer and RW
wine units.
400 series refrigeration column
RC 462/RC 472/RC 492
– Stainless steel interior with solid
anthracite aluminum elements
– Warm white and glare-free LED
light spots
– Net volume (24") 13.0 cu.ft., (30")
16.8 cu.ft., (36") 20.6 cu.ft.
– Opening assist for door with two
options:
1. Push-to-open function for
integration into handleless furniture
front
2. Pull-to-open function to facilitate
opening the door using a handle
– The drawers in the RC and RF
models are positioned at the same
height. With side-by-side
installation, the glass shelves and
door racks can be aligned on the
same level
– Flat stainless steel inner door,
full-length
– Almost invisible rail system for
shelves and door racks for flexible
positioning
– Solid anthracite aluminum door
racks
– One fresh cooling drawer 32°F
(0°C) with temperature control
from 32°F to 37°F (-1° to +3°C)
and one fresh cooling drawer with
manually adjustable humidity
– TFT touch display
– ENERGY STAR
®
certified
– Sabbath mode certified by Star-K
Operation
TFT touch display operation.
Clear text display.
Features
Dynamic cold air distribution.
Automatic defrosting with defrost
water evaporation.
Activated charcoal air filter.
Sabbath mode certified by Star-K.
When sabbath mode is active, the
appliance can only be opened using
a handle.
Open-door and malfunction alarm.
Home network integration for digital
services (Home Connect) wireless
via WiFi.
For further information please check:
home-connect.com.
Cooling
No-Frost technology with fast cooling.
Temperature adjustable from 35°F to
46°F (+2°C to +8°C).
4 safety glass shelves, white glass,
3 of which are individually adjustable
in height.
1 shallow, fully extendable drawer with
transparent front.
4 brilliant LED light spots with warm
white, glare-free light within cooling
area and drawers.
Flat door rail system with fully flexible
positioning of door racks.
3 height adjustable door racks, 1 of
which is extra deep.
Net volume (24") 13.0 cu.ft., (30")
16.8 cu.ft., (36") 20.6 cu.ft.
Fresh cooling close to 32°F (0°C)
1 large, fully extendable fresh cooling
32°F (0°C) drawer with transparent
front, illuminated
Temperature control via central TFT
display, temperature can be adjusted
from 30°F to 38°F (-1°C to +3°C).
Ideal for meat, fish and poultry.
Fresh cooling
1 fully extendable fresh cooling drawer
with transparent front, illuminated.
Humidity can be adjusted manually.
Ideal for fruit and vegetables.
Consumption data
Energy consumption
(24") 264, (30") 289, (36") 313 kWh/
year
Noise level 40 dBA.
Planning notes
Flat hinge.
Door hinge right, reversible.
Door opening angle of 115°, fixable
at 90°.
Max. door panel weight 95/53/90 lbs.
(43/24/41 kg)
Rating
Total rating: (24") 0.723, (30") 0.792,
(36") 0.858 kW/24h.
Total Amps: 15 A.
120 V / 60 Hz
Connecting cable 118" (3m),
detachable.
RA 460 013
Additional side heating element 110 V.
Required if appliances are installed
handle to hinge or hinge to hinge. Not
required if appliances are installed
more than 6" (160 mm) apart from
each other.
RA 460 020
Connecting element for vertically split
appliance fronts (for a flush front).
RA 464 611
Ventilation grill stainless steel
For 24" wide appliances.
RA 464 711
Ventilation grill stainless steel
For 30" (76.2 cm) wide appliances.
RA 464 911
Ventilation grill stainless steel
For 36" (91.4 cm) wide appliances.
Optional accessories
RA 430 100
Storage container with transparent lid,
anthracite
