- Use and care manual
41
Pyrolysis (self-cleaning) en-us
9 WARNING
Risk of burns!
; The appliance will become very hot on the
outside during the cleaning function. Never touch
the appliance door. Allow the appliance to cool
down. Keep children away from the appliance.
Do not clean parts or accessories in the self-clean oven.
Preparing the pyrolytic self-cleaning
feature
9 CAUTION
Risk of fire! Loose food remnants, fat and meat
juices may catch fire. Wipe the cooking
compartment with a damp cloth.
▯ Remove the worst soiling and food residues from the
oven.
▯ Clean the door seals, the inside of the door and the
glass pane by hand as these parts are not cleaned
during the pyrolytic self-cleaning cycle.
▯ Remove any loose parts from inside the cooking
compartment. The plug-in grids are pyrolysis-proof.
Make sure that nothing is left inside the cooking
compartment.
▯ Bush for the additional heating element at the back of
the cooking compartment: Make sure that the cover is
in the bush.
▯ Close the oven door.
Starting self-clean (pyrolysis)
1. Set the program selector to S.
2. The œ symbol is displayed. Confirm with ™.
3. The turn-off time for when the self-clean (pyrolysis)
will be completed is displayed. If preferred, the turn-
off time can be changed with the rotary selector.
Confirm with ™.
4. Remove all accessories and coarse soiling from the
oven interior. Confirm with ™.
5. Start with I. The cleaning time counts down on the
screen. If the turn-off time was changed, the time until
the self-clean (pyrolysis) starts counts down on the
screen. The oven light remains off.
After 3 hours, a signal sounds. A message will appear on
the screen. Once the appliance is cool, wipe out the
remaining ash from the oven with a damp cloth.
Note: The oven door is locked for your safety. After
cooling down, the door is unlocked as soon as the
temperature has dropped below 390 °F (200 °C).
Depending on the type of soiling, white deposits may
remain on the enamel surfaces. These deposits are
residue from the food and are harmless. They do not
affect how the appliance works. If required, you can
remove these residues using lemon juice and a soft cloth.
Cleaning the Accessories with the
Pyrolytic Self-cleaning Feature
Gaggenau baking trays and broiler pans are coated with
pyrolysis-resistant enamel. For optimal results when
cleaning the oven, we recommend removing all
accessories from the oven before initiating the pyrolytic
self-cleaning feature. This is the only way to achieve even
heat distribution.
If you wish to remove burnt-on residue from your baking
tray or broiler pan with the pyrolytic self-cleaning cycle,
please observe the following instructions:
Notes
▯ Remove the worst soiling, meat juices, and food
residues before initiating the pyrolytic self-cleaning
cycle. Food residues, grease, and meat juices may
catch fire during the pyrolytic self-cleaning cycle.
▯ Slide only one baking tray or broiler pan onto the
lowest rack in the oven.
▯ Push the baking tray or broiler pan in as far as it will
go.
▯ Wire rack, rotisserie spit, cast iron roaster, baking
stone, core temperature sensor, or other accessories
must not be cleaned in the pyrolytic self-cleaning
cycle.
▯ Broiler pans with stainless steel bushings can
discolor during the pyrolytic self-cleaning cycle. This
does not affect its usability.
3\URO\LV
_
)
