POWERPLANT AMPLIFIER MANUAL PP-AM300010 PP-AM200010 PP-AM120040 PP-AM60020 PP-AM100010
CONTENTS • AMPLIFIER SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 4 • AMPLIFIER INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 5 • FOUR CHANNEL AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 6 • TWO CHANNEL AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 8 • MONOBLOCK AMPLIFIERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 10 • TROUBLESHOOTING . . . .
ACCEPTABLE AMPLIFIER LOADS AMPLIFIER SPECIFICATIONS 4 Ohm 2 Ohm 1 Ohm PP-AM120040 YES* YES* NO PP-AM60020 YES* YES * NO PP-AM300010 YES YES YES 1 2 PP-AM300010 (Monoblock) PP-AM200010 (Monoblock) Class D-Class D-Class Max Power Rating 3000 Watts 2000 Watts Frequency Response 20Hz - 320kHz 20Hz - 320kHz PP-AM200010 YES YES YES Dimensions (mm) 436(L) x 278(W) x 60(H) 436(L) x 278(W) x 60(H) PP-AM100010 YES YES NO Power Ratings 850 Watts RMS per Channel @ 4 Ohms 1% THD
6. Front Input Level This control is used to match the input level of the amplifier to the output level of your source unit 1. Turn the amplifier level to zero. 2. Turn the volume of the source unit to ¾ and the bass and treble to zero. 3. Adjust the level control until the desired maximum volume is achieved without distortion. 4. Failure to follow these steps may cause permanent damage to the audio system. FOUR CHANNEL AMPLIFIER PP-AM120040 1 2 3 16 7.
. Input Connectors Choose the correct length RCA interconnects and run them to the RCA outputs of the source unit. Avoid running beside other looms and or power cable. TWO CHANNEL AMPLIFIER PP-AM60020 1 2 6. Input Level This control is used to match the input level of the amplifier to the output level of your head unit 1. Turn the amplifier level to zero. 2. Turn the volume of the head unit to ¾ and the bass and treble to zero. 3.
4. Output Connectors Line level output for connection to an additional amplifier MONOBLOCK AMPLIFIERS PP-AM100010, PP-AM200010, PP-AM300010 1 2 5 6 7 Input Connectors Choose the correct length RCA interconnects and run them to the RCA outputs of the source unit. Avoid running beside other looms and or power cable. 6. Input Level This control is used to match the input level of the amplifier to the output level of your head unit 1. Turn the amplifier level to zero. 2.
NOTES TROUBLESHOOTING PROBLEM Amplifier not switching on.
NOTES PUBLISHED BY FUSION ELECTRONICS LIMITED: © Copyright 2008 by FUSION Electronics Limited. All rights reserved. Specifications and design are subject to change without notice. 14 YOU CAN HELP PROTECT THE ENVIRONMENT! Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal center.
