Data Sheet Fujitsu CELSIUS R570 Workstation

Page 1 / 7 http://ts.fujitsu.com/celsius

Fujitsu recommends Windows® 7.

Data Sheet

Fujitsu CELSIUS R570

Workstation

Your Compact “Powerhouse” Workstation

If you have intensive graphics and processor requirements, the Fujitsu CELSIUS R570 dual-processor

workstation offers you the high-end performance you need. Designed for 24/7 operations, this

individually congurable workstation signicantly enhances your productivity. It’s a high quality,

reliable and usable solution that features best-in-class noise emissions and runs all your application

smoothly, thanks to comprehensive ISV certications.

Performance

Higher productivity

 High performance multi-core processors, hard disk drives and next generation graphics

subsystems

Ergonomics

Quiet system for a pleasant working environment

 Optimized thermal management, low-noise chassis and silent fans

Reliability

System stability for the complete lifecycle

 High product standards thanks to top-quality components and comprehensive testing in certied

in-house laboratories for 24/7 operation

Certification of workstation applications

Stability, compatibility and performance for the main workstation applications

 Comprehensive support for ISV applications and ease of integration into existing IT networks

Expandability

Excellent expandability for future demands

 Increased memory capacities of up to 96 GB

Summary of content (7 pages)

PAGE 1
Data Sheet Fujitsu CELSIUS R570 Workstation Fujitsu recommends Windows® 7. Data Sheet Fujitsu CELSIUS R570 Workstation Your Compact “Powerhouse” Workstation If you have intensive graphics and processor requirements, the Fujitsu CELSIUS R570 dual-processor workstation offers you the high-end performance you need. Designed for 24/7 operations, this individually configurable workstation significantly enhances your productivity.
PAGE 2
Data Sheet Fujitsu CELSIUS R570 Workstation Fujitsu recommends Windows® 7. Components Processor Operating systems Operating system Operating system compatible Operating system notes Memory modules Page 2 / 7 Intel® Xeon® processor X5675 (6 Cores / 12 Threads, 3.06 GHz, 12 MB) Intel® Xeon® processor X5675 (6 Cores / 12 Threads, 3.06 GHz, 12 MB, 6.4 GT/s) Intel® Xeon® processor X5672 (4 Cores / 8 Threads, 3.20 GHz, 12 MB) Intel® Xeon® processor X5672 (4 Cores / 8 Threads, 3.20 GHz, 12 MB, 6.
PAGE 3
Data Sheet Fujitsu CELSIUS R570 Workstation Fujitsu recommends Windows® 7. Graphics add on cards (optional) Ultra-high-end 3D: NVIDIA® Quadro® 6000, 6 GB, 448 cores, PCIe x16, 1x DVI-I, 2x DisplayPort, 2x DVI/VGA Ultra-high-end 3D: NVIDIA® Quadro® 5000, 2.
PAGE 4
Data Sheet Fujitsu CELSIUS R570 Workstation Base unit Mainboard Mainboard type Formfactor Chipset Processor socket Processor quantity maximum Memory slots Supported capacity RAM (max.) Memory notes CELSIUS R570-2 Fujitsu recommends Windows® 7. CELSIUS R570-2 POWER LAN Audio codec Audio features D2628 extended CEB Intel® 5520, Intel® 82801JIB ICH10 LGA 1366 2 6 (3 per processor) 96 GB In configurations with 4 GB and more the visible memory may be reduced to approximately 3.
PAGE 5
Data Sheet Fujitsu CELSIUS R570 Workstation Noise for standard configuration (HDD, ODD, FDD) Office mode 23 dB(A) Noise notes / description depending on configuration Dimensions / Weight / Environmental Dimensions (W x D x H) Weight Weight notes Operating ambient temperature Operating relative humidity Compliance Product Model Germany Europe USA/Canada Global China Compliance link Security System protection Audit proof protection Access protection Additional Software Additional software (preinstalled)
PAGE 6
Data Sheet Fujitsu CELSIUS R570 Workstation Manageability DeskView components Supported standards Manageability link Fujitsu recommends Windows® 7. On/Offline remote client management Detailed system inventory management and reports BIOS Management Remote power management System notifications Security Remote Control DeskView Helpdesk Integration WMI BootP (made4you) PXE WoL (Wake on LAN) http://ts.fujitsu.
PAGE 7
Fujitsu recommends Windows® 7. Data Sheet Fujitsu CELSIUS R570 Workstation More information Fujitsu platform solutions More information Copyrights In addition to Fujitsu CELSIUS R570, Fujitsu provides a range of platform solutions. They combine reliable Fujitsu products with the best in services, know-how and worldwide partnerships. Learn more about Fujitsu CELSIUS R570, please contact your Fujitsu sales representative or Fujitsu Business partner, or visit our website. http://ts.fujitsu.
