Technical data
Technical data
Tablet PC
General
Processor
Intel® BayTrail-T™ SoC, Quad Core Intel®
Atom™ Processor Z3770 (2 .4 GHz)
Main memory (SO DIMM) 4GB DiMM onboard
Electrical data
Safety regulations complied with CE
Protection class II
Maximum power consumption: (when the Tablet
PC is switched on, connected to the attachable
keyboard and the battery is charged):
36 W
Touchscreen
Size 10.1" WQXGA Wide View TFT
Resolution
2560 x 1600 pixels/16 million colours
Pixel class II
Brightness control 12 levels
Technology Wide-View High-Bright D isplay with LED
background lighting
Digitizer and glass panel Dual digitizer with glare touch screen
Cameras
• Front: HD camera
• Back: 8 megapixel, autofocus, mobile light
Graphic
scard
Chip
Intel H
D graphics
Maximum r esolution on external d isplay:
1920 x 1080 (1080p)
Dimensions
Width x d epth x height
267.
0 x 180.8 x 9.9 mm / 16.0 mm (depending
on ba
ck cover)
Weight depending on configuration from 640 g
Input devices
Tablet buttons 3 keys
Pen Active pen with one press-button
Slots
Memory card slot
1xmicroSDCard
SIM card slot 1 x m icro SIM Card
Ports
Headphone port 3.5 mm stereo mini jack
Docking port 1 x
USB (Universal Serial Bus) 1 x USB 3.0, 1 x micro USB 2.0
Ambient conditions
Fujitsu 81
