STYLISTIC Q550 Operating manual Innovative technology 7 Ports and controls 9 Important notes 11 First-time setup of your device 17 Working with the Tablet PC 20 Security functions 54 Connecting external devices 61 Settings in BIOS Setup Utility 65 Troubleshooting and tips 68 Technical data 76 Manufacturer’s notes 78 Index 85
Microsoft, MS and Windows are registered trademarks of the Microsoft Corporation. Adobe Reader is a trademark of Adobe Systems Incorporated. MultiMediaCard is a registered trademark of Infineon Technologies AG Sony and Memory Stick are registered trademarks of Sony Electronics, Inc. All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged.
Contents Contents Innovative technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Further information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Notational conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents Memory cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Supported format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Inserting the memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Removing the memory card . . . . . . . . . .
Contents The external monitor is blank or the image is unstable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . The cursor does not correctly follow the pen movements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pen input not working . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . The Tablet PC does not start after switch on . . . . . . . . . . . . . . . . . . . . . . . .
Contents 6 Fujitsu Technology Solutions
Innovative technology Innovative technology ... and ergonomic design make your device a reliable and convenient companion. The device boots very quickly, is ready for immediate use and offers a particularly long operating time because of its high capacity battery. The user-friendly "BIOS Setup Utility" offers powerful password protection functions which can be used to control your Tablet PC’s hardware and protect your system better against unauthorised use.
Innovative technology Notational conventions Pay particular attention to text marked with this symbol. Failure to observe these warnings could pose a risk to health, damage the device or lead to loss of data. The warranty will be invalidated if the device becomes defective through failure to observe these warnings. Indicates important information for the proper use of the device.
Ports and controls Ports and controls This chapter presents the individual hardware components of your device. It gives you an overview of the device’s indicators and connections. Please familiarise yourself with these components before you start to work with the device.
Ports and controls Rear 1 2 3 4 5 8 1 2 3 4 10 = = = = Battery compartment WebCam Memory card slot Fingerprint sensor 5 6 7 8 = = = = 7 8 6 USB port Headphone port HDMI port Microphones Fujitsu Technology Solutions
Important notes Important notes Notes Importantnotes This chapter contains essential safety information which must be followed when working with your Tablet PC. The other notes provide useful information on your Tablet PC. Safety notes Notes Safetynotes Please follow the safety notes provided in the "Safety/Regulations" manual as well as the safety notes given below. Please pay special attention to the sections in the manual marked with the symbol on the left.
Important notes Protecting the display screen The device is not waterproof. Do not pour liquids on the system or wash it with a heavily soaked cloth. Do not place items on the top of the display, or damage may occur. During normal use of the device, small particles from the environment can become embedded in the pen tip and scratch the screen. To prevent this, make sure that a screen protector is applied. The warranty does not cover a scratched screen.
Important notes ► Align the screen protector on the edges of the screen as illustrated and lay it on the screen with the adhesive side downward. ► Make stroking movements towards the outside edges in order to remove any air bubbles. ► Press the edges firmly.
Important notes To ensure a good seal between the screen protector and the display, do not lift the screen protector from the display once it has been applied. ► Carefully lift the plastic protective coating at the angled corner and pull it from the screen. You can now touch the screen with the pen. ► To remove all adhesive residue and prevent the tip of the pen from squeaking, wipe the screen protector with a soft, dry cloth. The adhesive sets completely within 48 hours.
Important notes Energy saving Energysaving Energy Notes If you will not be using your Tablet PC, switch it off. Switch off any connected external devices when they are not in use. If you use the energy saving functions, the Tablet PC uses less power. You will then be able to work for longer before having to recharge the battery. Energy efficiency is increased and the environmental impact is reduced. You save money while protecting the environment.
Important notes Transporting the Tablet PC Protect the Tablet PC from severe shocks and extreme temperatures (e.g., direct sunlight in a car). ► ► ► ► ► If your device has an optical drive, remove all data media (e.g. CD, DVD) from the drives. Switch off the Tablet PC. Unplug the mains adapter and all external devices from the power socket. Disconnect the mains adapter cable and the data cables for all external devices.
First-time setup of your device First-time setup of your device Gettingstarted First-timesetup Please read the chapter "Important notes", Page 11. If your device is equipped with a Windows operating system, the necessary hardware drivers and supplied software are already pre-installed. Before you switch on the device for the first time, connect it to the mains voltage using the mains adapter, see "Mains adapter connecting", Page 18.
First-time setup of your device Selecting a location Selectinga location Mainsadapter Device Select a suitable location for the device before setting it up. Follow the instructions below when doing so: • Never place the device or the mains adapter on a heat-sensitive surface. The surface could be damaged as a result. Never place the device on a soft surface (e.g. carpeting, upholstered furniture, bed). This can block the air vents and cause overheating and damage.
First-time setup of your device Switching on the device for the first time Switchingon for thefirsttime On devices with ON/OFF switch for wireless components: Slide the ON/OFF switch for wireless components to the ON position before switching on the device. When you switch on the device for the first time, the supplied software is installed and configured.
Working with the Tablet PC Working with the Tablet PC TabletPC TabletPC,operation This chapter describes the basics for operating your Tablet PC. You can find instructions on how to connect external devices (e.g. mouse, printer) to the Tablet PC in the chapter "Connecting external devices", Page 61. Please refer to the notes in "Important notes", Page 11.
Working with the Tablet PC Switching on the Tablet PC TabletPC:switching on Suspend/Resumebutton Power-onindicator 2 1 ► Slide the ON/OFF switch (1) to the right to switch on the Tablet PC. The ON/OFF switch returns automatically to its original position. The power-on indicator (2) lights up whenever the system is switched on.
Working with the Tablet PC Handwriting recognition under Windows 7 Handwriting recognition under Windows 7 currently supports the following languages: English, German, French, Italian, Japanese, Korean, Chinese (traditional and simplified), Dutch, Portuguese, Spanish, Brazilian, Norwegian (Bokmål and Nynorsk), Swedish, Finnish, Danish, Polish, Rumanian, Serbian (Cyrillic and Latin script), Catalan, Russian, Czech and Croatian.
Working with the Tablet PC Select display orientation (portrait or landscape orientation) Displayorientation Portraitorientation Landscapeorientation You can choose to use either portrait or landscape orientation for the display. Press the Tablet button to switch between portrait and landscape orientation. Windows 7 You can change these settings in the Fujitsu menu or under Start - (Settings -) Control Panel - Hardware and Sound - Display - Settings.
Working with the Tablet PC Actions with one finger Action Selecting objects (click with the left mouse button) Starting programs (double-click with the left mouse button) Moving objects/windows (drag with left mouse button pressed, Drag & Drop) Opening a context menu (click with the right mouse button) Moving the cursor 24 Description ► With your finger, tap once briefly on the object. ► With your finger, tap twice briefly in quick succssion on the program icon.
Working with the Tablet PC Actions with two fingers Action Scrolling Description ► Position two fingers on the touchscreen. ► Move your fingers upwards to scroll up. or ► Move your fingers downwards to scroll down. Rotating ► Position the thumb on the touchscreen, then turn the picture clockwise or counter-clockwise using your index finger.
Working with the Tablet PC Action Increasing or decreasing the view Description ► Position two fingers on the touchscreen and move them apart to increase the view. or Blocking context-sensitive menus 26 ► Position two fingers on the touchscreen and move them together to decrease the view. ► With two fingers, tap twice briefly in quick succession on the touchscreen.
Working with the Tablet PC Actions with three fingers Action Maximising or minimising current window Description ► Position three fingers on the touchscreen and move them upwards to maximise the window. or ► Position three fingers on the touchscreen and move them downwards to minimise the window.
Working with the Tablet PC Action Displaying and rotating current window in 3D carousel layout Minimising all windows and displaying the desktop 28 Description ► Tap the touchscreen with your three fingers to display the 3D carousel. ► Hold your fingertips pressed to change the 3D carousel layout. ► With three fingers, tap the touchscreen twice briefly in quick succession.
Working with the Tablet PC Action Scrolling through all open files in a program Description ► Position three fingers on the touchscreen and move them to the side (left or right) over the touchscreen. Displaying context menu and selecting entry ► Position two fingers on the touchscreen. A context menu is displayed on the screen. ► With one finger on the other hand, tap on an entry in the context menu. The entry is selected.
Working with the Tablet PC Actions with four fingers Action Displaying a menu with context-sensitive web applications with one hand You can select a word, sentence, paragraph or an item Description ► Tap briefly on the touchscreen with four fingers on one hand then lift your fingers from the screen. A menu with context-sensitive web applications is displayed.
Working with the Tablet PC Action Enlarging the area Description ► To magnify an area of a document, position two fingers of each hand in a rectangle on the touchscreen as shown. The selected area will be magnified. ► Place one finger on the touchscreen to move the rectangle around the touchscreen to magnify several areas.
Working with the Tablet PC Action Paging through (fast scrolling) Description ► Position four fingers on the touchscreen and move them upwards to scroll up. or ► Position four fingers on the touchscreen and move them downwards to scroll down. The distance you sweep your fingers indicates how far you move up or down.
Working with the Tablet PC Using the stylus pen 1 = pen tip 3 2 2 = pen button 3 = eyelet for pen cord 1 You can use the pen on your Tablet PC as an electronic writing implement to select items, and to navigate through programs on it. Programs that support handwriting recognition also allow you to write characters directly on the screen with the pen. You can also use the pen as a drawing tool. The Tablet PC is supplied with a pen cord which you can attach to the eyelets on the pen and on the Tablet PC.
Working with the Tablet PC The screen responds to entries made with the tip of the finger or the pen when the tip of the finger or the pen is in direct contact with the screen. You can use the pen to run all functions for which you would otherwise use a mouse. The pen does not support erasing functions. Handling Mouse Selecting menu Click with the left-hand mouse button. items Starting programs Double click with the left-hand mouse button.
Working with the Tablet PC Changing the pen tip With use, the pen tip may become worn or may pick up foreign particles that can scratch the screen. A damaged or worn tip may not move freely, causing unpredictable results when using the pen. If these problems appear with your pen, you should change the pen tip. ► Pull the pen tip from the pen. ► Replace the pen tip with one of the replacement tips that were supplied your pen.
Working with the Tablet PC Installing a pen battery ► Insert the new battery in the pen (1). ► Close the pen cap (2). 2 1 Installing a pen cord You should attach the pen with a pen cord to prevent accidentally dropping or losing it. ► Fasten the pen cord to the pen eyelet and to the eyelet on the Tablet PC.
Working with the Tablet PC Tablet buttons Your Tablet PC is fitted with three multi-functional tablet keys. You can navigate on the screen with a simple press of a button, call preset applications or ones that you have set yourself. Basic functions before the device has booted You can configure the functions in the table below yourself. The TPM PPI (Physical Presence Interface) menu is available only if your system has a TPM module.
Working with the Tablet PC To open the Windows Advanced Boot Options menu, first connect an external keyboard to your device. During the boot process, press the F8 key quickly in succession. Alternatively, you can start the Fujitsu Recovery Program while the operating system is running. For more information, please refer to the "Recovery" manual.
Working with the Tablet PC Webcam Webcam Your device has two WebCams: one on the front side of the device and one on the rear. Depending on the software used, you can use your Webcam to take pictures, record video clips or take part in web chats. • • • • The picture quality depends on the lighting conditions and the software being used. You can only operate the webcam with a particular application (e.g. an Internet telephony program or a video conferencing program which supports a webcam).
Working with the Tablet PC Charging, caring for and maintaining the battery Battery The Tablet PC battery can only be charged when the ambient temperature is between 5°C and max. 35°C. You can charge the battery by connecting the Tablet PC to the mains adapter (see "Mains adapter connecting", Page 18). If the battery is running low you will hear a warning alarm. If you do not connect the mains adapter within five minutes of the warning alarm described above, your Tablet PC will switch off automatically.
Working with the Tablet PC Removing the battery Please observe the safety information in chapter "Important notes", Page 11. Remove the power plug from the mains outlet! ► Switch the device off. The device must not be in energy-saving mode. ► Remove all the cables from the device. ► Turn the device over and place it on a stable, flat and clean surface. If necessary, lay an anti-slip cloth on this surface to prevent the device from being scratched.
Working with the Tablet PC Installing battery 1 3 2 ► Slide the release button in the direction of the arrow (1). ► Slide the release button in the direction of the arrow (2) and hold it in place. ► Push the battery into the battery compartment until you feel it engage (3).
Working with the Tablet PC Battery capacity display You can check the charge status directly on the battery itself. ► Remove the battery (see "Removing and installing the battery", Page 40). PUSH 1 a ► Press the test key (1). The LED (a) lights up in one of the following colours: LED indicator Green Orange Red LED not lit Fujitsu Technology Solutions State of charge The battery is between 50 % and 100 % charged. The battery is between 10 % and 49 % charged.
Working with the Tablet PC Using the power-management features Battery Power The Tablet PC uses less power when the power management features are enabled. You will then be able to work longer when using the battery before having to recharge it. Power efficiency is increased and environmental pollution reduced. By choosing the best power options, you can make significant savings and at the same time help protect the environment.
Working with the Tablet PC Memory cards Slot Your Tablet PC is equipped with an integrated memory card reader. Observe the manufacturer’s instructions when handling the memory cards. Memory card Supported format The memory card reader supports the following format: • Secure Digital (SDTM card) Inserting the memory card ► Carefully slide the memory card into the slot. The label should be facing upward. Do not apply excessive force, as otherwise the delicate contact surfaces could be damaged.
Working with the Tablet PC Removing the memory card Memorycard In order to protect your data, always follow the correct procedure for removing the card outlined below. You can stop the memory card via the corresponding icon in the task bar: ► Tap on the symbol. ► Select the card you want to stop and remove. ► Tap OK. Wait for the dialogue box which tells you that it is now safe to remove the memory card. ► On devices with card locking: Press on the storage card (1).
Working with the Tablet PC Inserting the SIM card ► Remove the battery, see Chapter "Removing the battery", Page 41. ► Slide the SIM card into the slot (1) until it engages, as shown in the battery compartment. The notch shows to the left, the chip to the bottom. 1 ► Install the battery again, see Chapter "Installing battery", Page 42. Removing a SIM card ► Remove the battery, see Chapter "Removing the battery", Page 41. ► Press on the edge of the SIM card so that it jumps up slightly out of the slot.
Working with the Tablet PC Switching the wireless components on and off Before switching on your device for the first time, the on/off switch for radio components must be in the "ON" position. ► Slide the ON/OFF switch into the "ON" position to activate the radio components. or ► Slide the ON/OFF switch to the "OFF" position to deactivate the radio components.
Working with the Tablet PC Setting up WLAN access • Requirement: A WLAN must be available and you must have the corresponding access information. Information on configuring the WLAN access can be found in the documentation for your operating system. Access via UMTS If you ordered an integrated UMTS module with your system, you can enjoy optimum reception and maximum energy efficiency without awkward cables or antennas. The optional UMTS module is ready for use straight away.
Working with the Tablet PC Your Cradle (optional) Your Cradle is a device that helps you to quickly connect your Tablet PC to your peripheral devices, such as a printer, mouse, etc. You only need to dock the Tablet PC in order to work with your peripheral devices.
Working with the Tablet PC Setting up the Cradle Select a suitable location for the Cradle before setting it up. Follow the instructions below when doing so: • • • Place the Cradle on a flat, stable, nonslippery surface. Never place the Cradle and the mains adapter on a heat-sensitive surface. Do not expose the Cradle to extreme environmental conditions. Protect the Cradle from dust, humidity and heat.
Working with the Tablet PC ► Remove the power plug of the mains adapter from the mains socket. ► Pull the mains adapter cable out of the DC jack (DC IN) of the Tablet PC. 2 1 4 3 ► Position the Tablet PC so that it is in line with the storage space of the Cradle. ► Push the Tablet PC on to the Cradle in the direction of the arrow (1) until you notice it engage with the plug. ► Plug the DC output connector on the mains adapter into the DC input connector (DC IN) on the Cradle (2).
Working with the Tablet PC Disconnecting the Tablet PC from the Cradle If you connect the Tablet PC to the Cradle during operation, problems can occur. We recommend that the Tablet PC is switched off or that the appropriate undocking function provided by the operating system is executed. ► Switch off the Tablet PC. ► Open the clip on the rear side of the Cradle. 1 ► Lift the Tablet PC from the Cradle in the direction of the arrow (1), while supporting the underneath of the Cradle.
Security functions Security functions Securityfunctions Your Tablet PC has several security features that you can use to secure your system from unauthorised access. This chapter explains how to use each function, and what the benefits are. Please remember that in some cases, for example, forgetting your password, you may be locked out and unable to access your data.
Security functions Configuring password protection in BIOS Setup Utility To navigate more easily in the BIOS Setup Utility, you can use an external USB keyboard. Before using the various options for password protection in the BIOS Setup utility to increase data security, please observe the following: Make a note of the passwords and keep them in a safe place. If you forget your supervisor password you will not be able to access your Tablet PC.
Security functions Setting supervisor and user password ► Start the BIOS Setup Utility and go to the Security menu. ► Select the Set Supervisor Password field and press the Enter key. With Enter new Password: you are asked to enter a password. ► Enter the password and press the Enter key. Confirm new Password requires you to confirm the password. ► Enter the password again and press the Enter key. Changes have been saved is a confirmation that the new password has been saved.
Security functions Password protection for booting of the operating system With the supervisor password you have set in the BIOS Setup Utility (see section "Setting supervisor and user password", Page 56), you can also prevent booting of the operating system. Operating system Activating system protection ► ► ► ► Start the BIOS Setup Utility and go to the Security menu. Select the Password on Boot option and press the Enter key.
Security functions Password protection for the hard disk Passwordprotection: The had disk password prevents unauthorised access to the hard disk drives and is checked internally each time the system is booted. The condition for this is that you have assigned at least the supervisor password. Activating hard disk protection ► Call up the BIOS Setup and select the Security menu.
Security functions SmartCard reader Securityfunctions Securityfunctions, SmartCards are not supplied as standard equipment. You can use all SmartCards that comply with the ISO standard 7816-1, -2 or -3. These SmartCards are available from various manufacturers. With the appropriate software you can use your SmartCard as an alternative to password protection, but also as a digital signature, for encrypting your e-mails or for home banking. We recommend that you always use two SmartCards.
Security functions Trusted Platform Module (TPM) (device-dependent) Trusted Platform Module TPM To use the TPM, you must activate the TPM in the BIOS Setup before the software is installed. The condition for this is that you have assigned at least the supervisor password (see "Security functions", Page 54). Enabling TPM • ► ► ► Requirement: You have assigned a supervisor password, see "Security functions", Page 54. Call up the BIOS Setup and select the Security menu.
Connecting external devices Connecting external devices Under all circumstances, please observe the safety notes provided in the "Important notes", Page 11 chapter before connecting or disconnecting any devices to or from your Tablet PC. Always read the documentation supplied with the device you wish to connect. Never connect or disconnect cables during a thunderstorm. Never pull at a cable when disconnecting it. Always grasp the plug.
Connecting external devices HDMI port HDMIport The HDMI port of your Tablet PC can be used to connect an external amplifier, LCD TV or a plasma TV with an HDMI connection. ► Connect the data cable to the external device. ► Connect the data cable to the HDMI port of the Tablet PC. Some LCD televisions have only two loudspeaker connections and therefore cannot reproduce Dolby digital or DTS. In order to reproduce the sound, you must go into Windows and adjust the sound settings.
Connecting external devices Connecting USB devices USBports On the USB ports, you can connect external devices that also have a USB port (e.g. a DVD drive, a printer, a scanner or a modem). USB devices are hot-pluggable. This means you can connect and disconnect devices while your operating system is running. USB 2.0 has a data transfer rate of up to 480 Mbit/s. Additional information can be found in the documentation for the USB devices. ► Connect the data cable to the external device.
Connecting external devices Headphone port Connectingaudio devices Connectingheadphones Audioports Via the headphone port, you can connect either a headphone or an external speaker to your Tablet PC. ► Connect the audio cable to the external device. ► Connect the audio cable to the headphone port of the Tablet PC. The internal loudspeakers are disabled. If you purchase a cable from a retailer, please note the following information: The headphone port on your Tablet PC is a "3.5 mm jack socket".
Settings in BIOS Setup Utility Settings in BIOS Setup Utility BIOS SetupUtility System Setup Configuration,BIOSSetupUtility Hardwareconfiguration settings,BIOSSetupUtility configuration To navigate more easily in the BIOS Setup Utility, you can use an external USB keyboard. The BIOS Setup Utility allows you to set the system functions and the hardware configuration for the Tablet PC. When it is delivered, the Tablet PC is set to factory default settings.
Settings in BIOS Setup Utility Operating BIOS Setup Utility BIOS SetupUtility Use the touchscreen to operate the function keys in the BIOS Setup Utility. Tap on any element in the BIOS Setup menus or tap on the function or cursor keys indicated on the bottom of the screen. Press the F1 key to display help on the operation of the BIOS Setup Utility. The description of the individual settings is shown in the right-hand window of the BIOS Setup Utility.
Settings in BIOS Setup Utility Exiting BIOS Setup Utility BIOS SetupUtility You need to select the desired option in the Exit menu and activate it by pressing the Enter key: Exit Saving Changes - save changes and exit BIOS Setup Utility ► To save the current menu settings and exit the BIOS Setup Utility, select Exit Saving Changes and Yes. The Tablet PC is rebooted and the new settings come into effect.
Troubleshooting and tips Troubleshooting and tips Fault Tips Troubleshooting Follow the safety notes in the "Safety/Regulations" manual when connecting or disconnecting cables. If a fault occurs, try to correct it as described. If you fail to correct the problem, proceed as follows: ► Make a note of the steps and the circumstances that led to the fault. Also make a note of any error messages displayed. ► Switch the Tablet PC off. ► Please contact the Hotline/Service Desk.
Troubleshooting and tips The Tablet PC’s date or time is incorrect Summer Buffer Dateisincorrect Incorrectdate/time Timenotcorrect Time,daylightsavings battery,load time Cause Time and date are incorrect. Date and time are still set incorrectly after switching on the Tablet PC. Troubleshooting ► With the BIOS-Setup-Utility, you can set the date and time in the main menu. ► Please contact your sales outlet or our Hotline/Service Desk.
Troubleshooting and tips The external monitor remains blank Monitor Cause Monitor is switched off. Power saving has been activated (monitor is blank). Brightness is set to dark. Screen output is set on the Tablet PC’s touchscreen. The external monitor’s power cable or data cable is not connected properly. Troubleshooting ► Switch the external monitor on. ► Press a key (external keyboard) or tap on the touchscreen. ► Adjust the brightness of the monitor.
Troubleshooting and tips The cursor does not correctly follow the pen movements Cause Pen incorrectly calibrated Fault elimination ► Calibrate the pen as shown under Hardware and Sound / Tablet PC Settings in the Control Panel, see "Setting the pen", Page 34 and "Calibrating the pen", Page 34. Pen input not working Cause Incorrect driver installed. Troubleshooting ► If your device is one which can only be operated using the pen, install the driver for the standard model.
Troubleshooting and tips The Tablet PC stops working Energysaving mode TheTabletPC Cause The Tablet PC is in energy saving mode. An application programme has caused the malfunction. The battery is dead. Troubleshooting ► Leave energy saving mode. ► Close the application program or restart the Tablet PC (by restarting the operating system or switching the device off and back on again). ► Charge the battery. or ► Insert a charged battery. or ► Connect the mains adapter to the Tablet PC.
Troubleshooting and tips The battery discharges too quickly Battery: Cause The battery is either too hot or too cold. In this case the battery indicator flashes. Troubleshooting ► Bring the Tablet PC up/down to a normal temperature again. ► If the operating time of the battery life is extremely short, the battery is probably too old. Replace battery if necessary. You may have an application running that ► Use the mains adapter as frequently as consumes a great deal of power due to frequent possible.
Troubleshooting and tips User and/or supervisor SmartCard lost Cause User and/or supervisor SmartCard lost Troubleshooting ► If you have lost your User SmartCard, you can continue working with the Supervisor SmartCard and initialise a new User SmartCard or deactivate the SystemLock function. ► If you have lost the Supervisor SmartCard, you can continue working, but you no longer have all your rights and can no longer initialise a Supervisor SmartCard.
Troubleshooting and tips Error message/cause CMOS battery bad Resolution ► Contact your sales outlet or our customer service centre. If the error message occurs repeatedly, the buffer battery in the Tablet PC is flat. System CMOS checksum bad - default configuration ► Switch off the Tablet PC. used ► Switch on the Tablet PC. The system configuration information is ► Keep the "Change screen orientation" tablet incorrect. button pressed and switch on the Tablet PC.
Technical data Technical data Tablet PC General Processor Main memory (SO DIMM) Electrical data Safety regulations complied with Protection class Maximum power consumption: (Tablet PC on with battery charging) Touchscreen Size Resolution Pixel class Brightness control Technology Digitizer and glass panel Cameras Graphics card Chip Maximum resolution on external display: Dimensions Width x depth x height Weight depending on configuration Input devices Tablet buttons Pen Slots Memory card slot SmartCard slot
Technical data Ambient conditions Environment class DIN IEC 721 Mechanism class DIN IEC 721 Operating temperature Transport temperature (2K2) 7K1 7M2 5 ℃ .... 35 ℃ –15 °C .... 60 °C Rechargeable battery You can find information on the batteries used in your device at "http://ts.fujitsu.com/support". Rated voltage Rated capacity 4-cell lithium polymer battery 5240 mAh 7.2 V 38 Wh 2-cell lithium polymer battery 2620 mAh 7.2 V 19 Wh Mains adapter (40 W) Technicaldata Rated voltage 19 V Max.
Manufacturer’s notes Manufacturer’s notes Disposal and recycling Notes Information about this subject can be found on your Tablet PC or on our Internet pages. Declarations of Conformity Declarationofconformity The "Declarations of Conformity" for the device can be found at our Internet address under: "http://ts.fujitsu.com/ce". Fujitsu Technology Solutions hereby declares that your device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Manufacturer’s notes CE marking CEmarking CE marking for devices with radio component This equipment complies with the requirements of Directive 1999/5/EC of the European Parliament and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment and mutual recognition of conformity.
Manufacturer’s notes • Connect the equipment into an outlet that is on a different circuit than the receiver. • Consult the dealer or an experienced radio/TV technician for help. Notice to Users of the US Telephone Network Your Tablet PC may be supplied with an internal modem which complies with Part 68 of the FCC rules. On this Tablet PC is a label that contains the FCC Registration Number and the Ringer Equivalence Number (REN) for this equipment among other information.
Manufacturer’s notes • • Public transportation terminals where telephones are used to call taxis or to reserve lodging or rental cars. In hotel and motel rooms as at least ten percent of the rooms must contain hearing aid-compatible telephones or jacks for plug-in hearing aid compatible telephones which will be provided to hearing impaired customers on request.
Manufacturer’s notes Avant de connecter cet équipement à une ligne téléphonique, l’utilisateur doit vérifier s’il est permis de connecter cet équipement aux installations de télécommunications locales. L’utilisateur est averti que même la conformité aux normes de certification ne peut dans certains cas empêcher la dégradation du service. Les réparations de l’équipement de télécommunications doivent être effectuées par un service de maintenance agréé au Canada.
Manufacturer’s notes FCC Regulatory information for Tablet PCs with radio device Regulatoryinformation Federal Communications Commission statement This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
Manufacturer’s notes Regulatory Information/Disclaimers Installation and use of this radio device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment.
