C120-E360-06EN 2-13
2.6 RCI Setup for Replacement of an RCI Base Cabinet
2 Execute the setrci (8) command to initialize RCI settings.
2.6.4 Connecting an RCI cable
Connect the removed T-branch connector together with the RCI cable to the new RCI
host.
Note: Always do Confirming RCI initialization before reconnecting the RCI cable
to the RCI host.
2.6.5 Making an RCI address setting
Assign an RCI address to the new RCI host after replacement.
Make an RCI address setting on the new RCI host.
Specify the same RCI address as that assigned to the old RCI host.
• To specify an RCI address:
1 Execute the setrci (8) command, and specify an RCI address.
Specify a decimal number for the fifth and sixth digits of the target RCI address.
A decimal number in a range of 1 to 32 can be used.
XSCF> setrci -c init
The command completed successfully.
<Example> Specifying the RCI address 000102ff for the XSCF
XSCF> setrci -c set <2>
The command completed successfully.
