C120-E360-06EN 2-7
2.4 RCI Setup for Addition of an RCI Base Cabinet
2 Connect the T-branch connector to the RCI host to be added.
Note: Always do Confirming RCI initialization before connecting an RCI cable to
the RCI host.
2.4.4 Making an RCI address setting
Specify an RCI addresses in a range of 000102ff to 000120ff for the RCI host to be
added.
The RCI address must be unique in the existing RCI network.
RCI addresses must be assigned in the order of 000102ff, 000103ff, 000104ff, and so
on.
Specify the RCI address on the RCI host to be added.
• To specify an RCI address:
1 Execute the setrci (8) command, and specify an RCI address.
Specify a decimal number for the fifth and sixth digits of the target RCI address.
A decimal number in a range of 1 to 32 can be used.
• To confirm the specified RCI address:
1 Execute the setrci (8) command to display the RCI status.
Confirm that the "address" value is correct.
To correct the RCI address, start again from RCI initialization.
<Example> Specifying the RCI address 000102ff for the XSCF
XSCF> setrci -c set <2>
The command completed successfully.
XSCF> setrci -c stat
HOST
address 000102ff
Inactive
The command completed successfully.
