2-2 C120-E360-06EN
CHAPTER 2 Setup of the RCI for Operation
2.2 RCI Setup for Initial Installation
This section explains the procedure for initial RCI setup, which assumes RCI settings
have not been configured.
Note: Perform this work when this system is not using any RCI I/O unit.
2.2.1 RCI setup flow
RCI setup for initial installation contains the following steps:
1 Confirming RCI initialization
2 Connecting RCI cables
3 Making an RCI address setting
4 Making an RCI construction setting
2.2.2 Confirming RCI initialization
Before connecting an RCI cable to an RCI host, confirm that RCI settings have been
initialized.
• To confirm RCI initialization:
1 Execute the setrci (8) command to display the RCI status.
Confirm that "address" is 000f7fff (initial address value).
If RCI settings have not been initialized, perform the next step.
2 Execute the setrci (8) command to initialize RCI settings.
XSCF> setrci -c stat
HOST
address 000f7fff
Inactive
The command completed successfully.
XSCF> setrci -c init
The command completed successfully.
