fi-5110C Image Scanner P3PC-1072-03EN Getting Started fi-5110C Image Scanner Getting Started
CONTENTS ■ Regulatory Information ........................................................ ii ■ Note, Liability ....................................................................... iv ■ Safety Precautions ................................................................ v Chapter 1 PREPARING THE SCANNER.................................. 1 1.1 Checking the Contents of the Scanner Package............. 1 1.2 Names of Parts ................................................................... 1 1.
INTRODUCTION Thank you for purchasing the fi-5110C Duplex Color Scanner. This document describes how to handle fi-5110C Duplex Color Scannerand basic operation methods. Before you start using fi-5110C Duplex Color Scanner, be sure to thoroughly read this manual to ensure correct use. The "Operator’s Guide" is stored on the Setup Disk. The guide provides useful and detailed information on Operations when you would like to using advanced features, daily maintenance of the scanner, replacement of consumables.
penetration of energy efficient computers and other office equipment. The program backs the development and dissemination of products with functions that effectively reduce energy consumption. It is an open system in which business proprietors can participate voluntarily. The targeted products are office equipment such as computers, monitors, printers, facsimiles, copiers, scanners, and multifunction devices. Their standards and logos are uniform among participating nations.
Manufacturer Symbols Used In This Manual PFU LIMITED International Sales Dept., Imaging Business Division, Products Group Solid Square East Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa 212-8563, Japan Phone : (81-44) 540-4538 ATTENTION This symbol alerts operators to particularly important information. Be sure to read this information. This symbol alerts operators to helpful advice regarding operation.
FUJITSU ISIS scanner driver, QuickScan™ image capturing software and Adobe® Acrobat®. About Maintenance The user must not perform repairs on this scanner. Contact the store where you purchased the scanner or an authorized FUJITSU Image Scanner service provider to have repairs done on this product. ■ Safety Precautions Wipe any dust from the power plug. Wipe off any dust from metal parts on the power plug or metal fittings with a soft, dry cloth. Accumulated dust can cause fire or electric shock.
Do not use the scanner if you smell a strange odor. If you detect heat coming from the device or detect other problems such as smoke, strange smells or noises, immediately turn off the scanner and then disconnect its power plug. Make sure that any smoke coming from it has stopped, before contacting the store where you bought the scanner or an authorized FUJITSU scanner service provider. CAUTION Do not install the scanner on unstable surfaces.
Disconnect the power plug from the power outlet when the scanner is not used for a long period of time. When the scanner is not going to be used for a long period of time, be sure to disconnect the power plug from the power outlet for safety. Do not install the scanner in direct sunlight. Do not install the scanner under direct sunlight or near heating apparatus. Doing so might cause excessive heat to build up inside the scanner, which can cause scanner trouble or even fire.
Chapter 1 PREPARING THE SCANNER 1.1 Checking the Contents of the Scanner Package ■ Rear When you open the scanner package, please handle the main unit and its attachments carefully. Make sure it contains all the parts listed in the package contents list that is included in the package box. If any parts are missing or defective, contact your sales representative. 1.2 Names of Parts USB Interface connector DC inlet Security Cable Slot This section describes the scanner parts.
1.3 Operator Panel The operator panel is located on the right side of the scanner. This panel is comprised of a Function Number display, four buttons and a LED. Function No display Function ■ Indications on the Function Number display ■ 8 Blinks only one time upon turning on the scanner. ■ P Indicates that the scanner has been turned ON and is being initialized. Send to Scan Power button LED Name ■ 1 Indicates that initialization has ended successfully. The scanner is now in "Ready Status".
Chapter2 INSTALLATION OF THE SCANNER 2.1 Installing the Scanner Application Both the scanner driver and image capturing application software (called "application" hereafter) must be installed on your PC. There are two types of drivers for scanner, The FUJITSU TWAIN 32 Scanner Driver and FUJITSU ISIS Scanner Driver, as well as two software applications, ScandAll 21 and QuickScan Pro™, are provided with this product. The following sections describe how to install each driver and application.
4. Click [TWAIN Driver] on the window below. 5. Error Recovery Guide Installation window appears. Error Recovery Guide is a software that displays troubleshooting information on screen when any scanner error occurs. Although this software’s installation is highly recommended, the performance of the scanner would not be affected if not installed. ATTENTION When you select [Yes] for installing the Error Recovery Guide, [Choose Setup Language] window appears.
3. Click [ScandAll 21] on the window below. For FUJITSU ISIS Scanner Driver ■ Preparation Remove the Setup CD-ROM from its package. ■ Installing the FUJITSU ISIS Scanner Driver 4. Select a language used for installation on [Choose Setup Language] window and click [OK]. ATTENTION Windows XP screenshots are used in this section as examples. The windows and operations may vary slightly depending on your OS. 1. Turn your PC on and log on to Windows.
■ Installing QuickScan Pro™ 4. Click [ISIS Driver] on the window below. "QuickScan Pro™" is an image capturing software that complies with the ISIS standard. The FUJITSU ISIS scanner driver enables you to capture images with a FUJITSU image scanner fi-series product ATTENTION 5. Error Recovery Guide Installation window appears. Error Recovery Guide is a software that displays troubleshooting information on screen if any scanner error occurs.
1. Insert the Setup CD-ROM in your CD drive. The will appear. 2. Click [Install Products]. 5. Enter the required information, then click [Next >] button. 3. Click [Error Recovery Guide] on the next screen. ATTENTION "QuickScan Pro™" included in the Setup CD-ROM is an evaluation version. For further use after the expiration of its evaluation period of up to 30 launches, it is necessary to purchase a fully functional version of QuickScan Pro™.
6. When the [InstallShield Wizard Complete] screen displays, click [Finish]. ATTENTION This window is not displayed aoutomatically when the "Auto play" setting of your computer is deactivated. In this case, please run "Auto play.exe" of this CD-ROM directly using the "Explore" or "My computer". 2. Select the language and Click [OK] button.
5. Follow the instructions to install the software. ATTENTION HINT ATTENTION Select "How to install" on the "Adobe Acrobat 7.0 Standard" window to learn more about Adobe Acrobat 7.0 installation. Refer to "Adobe Acrobat Help" about how to use Adobe Acrobat7.0. Notes for using Adobe Acrobat 7.0 When scanning a paper document and converting the image to PDF using Acrobat 7.0, unexpected images may be output when: 1.
2.3 Connecting the USB Cable 3. Connect the AC adapter. ATTENTION Use only the AC adapter provided by the manufacturer. Follow the procedure below to connect the USB cable. 1. Connect the USB interface cable to the USB interface connector. 1) Connect the AC cable to the AC adapter. 2) Connect the AC adapter connector to the scanner’s DC inlet. 2. Connect the other end of the USB interface cable to the PC. ATTENTION • Be sure to use the USB cable which comes as an accessory with this scanner.
2.4 Confirming Installation To confirm whether the installation was successful, perform a scanning operation with an application that complies with either the TWAIN regulations, such as ScandAll 21 or the ISIS regulations such as QuickScan ProTM. 6. Set scanning resolution, document size, etc. on the [TWAIN driver] window (for setting details of scanning) and click the [Scan] button. ■ Confirming with ScandAll 21 1. Load the documents on the scanner. For details on loading documents, refer to "2.
2. Start QuickScan Pro™. From the [Start] menu, select [Programs]-[QuickScan]-[QuickScan]. 3. Select [Select Scanner...] from [Scan] menu in QuickScan Pro™. HINT Refer to "QuickScan Overview" or "QuickScan Help" for information about QuickScan Pro™ functions and operations. On the [Start] menu, point to [Programs]-[QuickScan] and click the file. And, select fi-5110C from the list of [Scanner:], and then click the [OK] button. 4. Select [Preview Settings...] from the [Scan] menu.
Appendix 1 TROUBLESHOOTING ■ Troubleshooting checklist Symptom Scanner does not turn on. Check this item Remedy Have you pressed the power button on? Push the power button in to turn the scanner. Are the AC cable and AC adapter properly connected to the scanner? Correctly connect the AC cable and the AC adapter. Are you using the correct AC cable and AC adapter supplied with the scanner from the manufacture? You must use the AC adapter and cable supplied with your scanner by the manufacture.
Symptom Paper frequently multi feeds. Paper does not feed (pick error occurs frequently, or document stops midway).
■ Temporary error Indication ■ Device alarm (Non-Temporary error) Meaning Indication Meaning U1 Paper feed error E2 Trouble in the optical system (front). U2 Multi Feed error E3 Trouble in the optical system (back). U4 The ADF has been opened during scanning. E4 The motor’s fuse has blown out. E6 Trouble with the operator panel. E7 Trouble occurred with the EEPROM. E9 An error in the image memory. Ec An alarm in the memory.
Appendix 2 DAILY CARE WARNING When operating the scanner, the ADF’s inside glass becomes very hot. Before you clean inside the scanner, turn off its power and unplug the AC adapter from the outlet. Wait for at least 15 minutes. Do not turn off the scanner when you clean the Feed rollers or Eject rollers. ■ Parts to Clean and When Part to clean Pad ASSY Pick roller Standard Cleaning Cycle Clean these parts after every 1,000 scans.
Appendix 3 REPLACING CONSUMABLES WARNING During its operation, the inside glass of the ADF becomes very hot . Before replacing the consumables, turn the scanner off and unplug the AC adapter from the outlet. Wait at least 15 minutes. The illustration below demonstrates the locations of the replacement parts. Refer to "Chapter 5 Replacing Consumables" fi-5110C Operator’s Guide on the Setup CD-ROM.
fi-5110C Image Scanner Getting Started P3PC-1072-03EN Date of issuance: June, 2006 Issuance responsibility: PFU LIMITED Printed in China Copying of the contents of this manual in whole or in part and copying of the scanner application is forbidden under the copyright law. z The contents of this manual are subject to change without notice. z PFU LIMITED.
