Computer Products of America Image Scanner Operator's Guide fi-4990C

6-7
Paper length check
This function sets and detects a difference in paper length. You cannot change settings if they are set by
the host computer.
Remarks
Checked or not
Difference:
XX mm means that it is not regarded as an
error when the actual difference of paper length
is within the limits of ±XX mm.
LCD display
Paper Length Check
Options
On, Off (Default: Off)
10 mm, 15 mm, 20 mm (Default: 10 mm)
The following is an example of operation when you use this function.
1. In <<SETUP MODE>> initial screen, press
ENTER
.
The <<SETUP MODE>> menu screen (Paper
Length Check) appears.
2. Press
ENTER
.
The option select screen indicates the current
options with OFF blinking (blinking indicates
“changeable”).
3. Press or .
The displayed option changes (ON).
4. Press .
The current difference 10 mm blinks (blinking
indicates “changeable”).
5. Press or .
The displayed option changes (15 mm or 20 mm).
<<SETUP MODE>>
Paper Length Check
OFF 10 mm
<<SETUP MODE>>
Paper Length Check
Paper Length Check
ON 10 mm
Paper Length Check
ON 10 mm
Paper Length Check
ON 20 mm
