User's Manual

10
Contents/Precautions
Part
Materilal/Surface
treatment
Charger terminal ABS resin + stainless
steel/Nickel coating + gold
plating
Power key/Volume
keys/Camera key
PC resin/UV cured acrylic
coating
1Seg antenna
compartment
Polyester film
Side key fastener
plate
Stainless steel/Nickel
coating
Screws
・
Steel/Trivalent chromium
plated
・
Steel/Trivalent chromium
plated + silica coating
Battery terminal
(terminal section)
Beryllium copper/Gold
plating
Battery terminal
(socket section)
LCP
PCB protective
sticker
Polyester film
Communication
antenna protective
sticker
PC resin film
Warning label Polyester film
docomo
UIM
card slot
Fitting
section
LCP
Guide Stainless steel/Nickel
coating
Metal
terminal
section
Copper alloy/Nickel
coating + palladium nickel
coating + gold plating
Part
Materilal/Surface
treatment
Battery
pack
Battery
pack
nameplate
PET/UV matte varnish
printing
Battery
pack case
(terminal
section
side)
PA resin/Electrical
discharge fine-grain finish
Battery
pack case
(removal
clasp side)
PC resin/Electrical
discharge fine-grain finish
Terminal
section
Glass epoxy substrate/
Gold plating
Water leak
sticker
Woodfree paper
Handling precautions
General notes
●
Although the T-01C has waterproof
properties, do not immerse the FOMA
terminal in water, and do not let water
splash on the supplied or optional
accessories.
The battery pack, adapters (including
charger and conversion adapter for
charging), desktop holder and docomo UIM
card are not waterproof. Do not use them in
humid or steamy areas such as bathrooms
and avoid exposing them to rain and other
forms of moisture. If they are carried close to
skin, perspiration may cause internal
components to corrode and result in
malfunction. Note that if problems are found
to be due to moisture, they are not covered
by warranty and in some cases may be
irreparable. Even where repairs are possible,
repair charges will be incurred since such
damage is not covered by warranty.
●
Clean only with a soft dry cloth (such
as the type used for eyeglasses).
・
Forceful rubbing of the display with a
dry cloth may scratch the surface.
・
Note also that the display coating may
stain if moisture or soiling is left on the
surface for a long period.
・
Never use chemicals such as alcohol,
thinner, benzene or detergent, as these
agents may erase the printing on the
FOMA terminal or cause discoloration.
●
Occasionally clean terminals with a
dry cotton swab, etc.
Unclean terminals may result in poor
connections and loss of power. Keep
terminals clean with a dry cotton swab, etc.
Take care not to damage terminals while
cleaning them.
●
Do not place the FOMA terminal near
an air conditioning vent.
Condensation formed due to rapid
changes in temperature may cause
internal corrosion and lead to malfunction.
●
Do not apply excessive force to the
FOMA terminal and battery pack when
using them.
Carrying the FOMA terminal in a tightly
packed bag, or sitting on the FOMA
terminal in your pocket may damage the
display, internal components or battery
pack, or result in malfunction.
Keeping an external device connected to
the external connector terminal or stereo
earphone jack may damage the
connector or result in malfunction.
11
Contents/Precautions
●
Do not rub or scratch the display with
a metal object, etc.
May damage the display and cause
malfunction or breakage.
●
Read the respective manuals supplied
with the battery pack, adapters
(including charger and conversion
adapter for charging) and desktop
holder carefully.
Notes about the FOMA terminal
●
Do not forcefully press the surface of
the touch panel, or operate with a
pointed object such as a fingernail,
ballpoint pen, pin, etc.
May damage the touch panel.
●
Avoid using the FOMA terminal in
extremely high or low temperatures.
Use the FOMA terminal within the range
of a temperature between 5

C and 40

C
(limiting to temporary usage in bathrooms
over 36

C) and a humidity between 45%
and 85%.
●
Using the FOMA terminal close to
landline phones, TVs or radios may
have harmful effects on the operation
of such equipment. Move as far away
as possible from such items before
use.
●
Keep a separate memo and note
information stored in the FOMA
terminal.
DOCOMO shall not be liable for any loss
of content.
●
Do not drop or otherwise subject the
FOMA terminal to severe impact.
May damage the FOMA terminal and
cause malfunction.
●
When connecting an external device
to the external connector terminal or
stereo earphone jack, do not put it in
obliquely or do not pull it while it is
plugged in.
May damage the FOMA terminal and
cause malfunction.
●
The FOMA terminal becomes warm
while you are using or charging it but
this is not a malfunction.
●
Do not leave the camera in direct
sunlight.
May cause discoloration or burn-in.
●
Use the FOMA terminal with the
external connector terminal cover on.
If the cover is open, dust, water and
others enter inside and may cause a
malfunction.
●
Do not use the FOMA terminal without
the back cover.
May detach the battery pack or cause
malfunction or damage.
●
While using a microSD card or USB
device, do not remove them from the
FOMA terminal or turn off the FOMA
terminal.
May cause data loss or malfunction.
●
Do not place magnetic cards near the
FOMA terminal.
The stored magnetic data in cash cards,
credit cards, telephone cards, floppy
disks, etc. may be erased.
●
Do not place magnetized items near
the FOMA terminal.
Putting strong magnetism close to the
FOMA terminal may cause an error.
Notes about the battery pack
●
The battery pack is a consumable
product.
Though the usage time varies by
conditions of use, change the battery
pack if the battery level is extremely low
even after fully charged. Purchase a
specified new battery pack.
●
Charge the battery pack at ambient
temperatures between 5

C and 35

C.
●
The usage time for a battery pack
depends on the usage environment
and deterioration of battery pack.
●
Depending on usage conditions, the
battery pack may swell as it
approaches the end of its service life
but this will not cause problems.
●
Note the following when the battery
pack is stored.
・
The storage with the battery pack fully
charged (immediately after charging is
completed)
・
The storage with empty battery level
(cannot turn the FOMA terminal on)
May lower the performance or shorten
the life of the battery pack.
W
e recommend you store the battery
pack at a battery level of approximately
40% or the two-bar battery level icon
shown as a guide.
