USING SETUP MODE
User's Manual 5-11
Available functions of LCD types SETUP MODE are as follows.
Table 5.2 summarizes the purpose of each function.
Table 5.2 Setup Mode Functions(LCD)
Function Purpose
MENU1 and MENU2
Assigns print features to MENU1 and MENU2 on the
printer control panel.
HARDWRE
Changes the printer hardware options.
ADJUST
Changes the print position adjustment options.
CONFIG
Changes the configuration options.
GAP-ADJ
Adjust the gap between the print head and printing
paper.
SAVE&EXIT
Exits setup mode and saves any changes made while
in setup mode.
LIST
Prints a list of all currently selected options.
DEFAULT
Resets factory defaults in MENU1 and MENU2.
SUB FUNCTION
INITIAL
Resets factory defaults in MENU1, MENU2,
HARDWRE, ADJUST, CONFIG, GAP-ADJ.
SELF-TST
Runs the self-test.
HEX-DUMP
Prints hex dumps.
SELFDIAGNOSTIC
V-ALMNT
Checks and corrects vertical print alignment.
Detail of selecting items and options are almost same as LED type.
General difference of LCD type SETUP MODE is only SETUP method.
The LIST function prints a list of all the printer’s currently selected
options. This function is useful for checking the printer settings when
you first enter setup mode or just before you exit. To print a list of
options, load paper A4 size or more in advance and select list function.
Note
If paper runs out only LOAD button is available.
OVERVIEW OF
SETUP MODE (LCD)
PRINTING A LIST OF
SELECTED
OPTIONS(LCD)
