12. Hardware Specification
Printing system Thermal line-dot printing
Thermal head
configuration
Resolution: 8 dots/mm
Dot pitch: 0.125 mm (Length) x 0.125 mm (side)
Number of dot: 384 dots/line
Effective printing area: Approx. 48 mm
Half size character
Alphanumeric
Katakana
Kanji
Full size character
Printing speed
Image integrated printing
Max. 40 (mm/sec)
Half size character 12 x 24 32
Full size character/Kanji.non-Kanji
24 x 24 16
Half size character 8 x 16 48
Number of characters
printed
Alphanumeric
Katakana
Chinese character
Full size character/Kanji.non-Kanji
16 x 16 24
Alphanumeric
Katakana
Internal half size character (12 x 24)
Internal full size character (24 x 24)
Internal half size character (8 x 16)
Internal full size character (16 x 16)
Registered half size character (12 x 24)
Registered full size character (24 x 24)
Registered half size character (8 x 16)
Registered full size character (16 x 16)
Character type
Kanji
Non-Kanji, Kanji JIS Class I, Class II level
(JIS C6226-1983)
Extended print mode
Horizontal double size, backward printing, reverse video, vertical double size, x4
size
Image mode Max. No. of dots/line: 384
IrDA
Communication method: IrDA Ver 1.2
Baud rate: 9,600 bps, 19,200 bps,
38,400 bps, 115.2 kbps
Communication mode: Semi duplex
Protocol stack: IrLAP, IrLMP, IrIAS, TinyTP,
IrCOMM
RS-232C
Communication mode: Semi/Full duplex
Baud rate: 9.600 bps (Max. 115.2 kbps)
Interface
Bluetooth
Communication method: Ver 1.1
Modulation method: FHSS/GFSK
Transmission speed: 460 kbps
Profile: SPP
Input supply voltage: Rating 100VAC to 240VAC
Output voltage: 5 VDC (Rating)
Output current: 1.5 A (Rating)
AC adapter
External dimensions Main frame: 73(W) x 48(H) x 20(D)
Cable: 1.8 m
Battery pack
Kind: Lithium ion secondary battery pack, 1 parallel, 1 serial
Life: Approx. 1 year (varies depending upon use conditions)
Operating temperature
and humidity
Temperature: 0 - 50 ℃ (5-40 ℃ for printing quality assurance)
0 - 40 ℃ (When AC adapter is used)
Humidity: 20 - 50%RH (No condensation shall be found)
Storage temperature
and humidity
Temperature: -20 – 60 ℃
Humidity: 5 – 90%RH (No condensation shall be found)
Structure
External dimensions: 84(W) x 135(H) x 44(D)
Weight: Up to 270 g (Paper and battery included)
