Installation Instructions

Technical data：
Operating voltage DC 12V
Interface 1 INTERNET port, 1 LOCAL port
Operating temperature -5℃～50℃
Operating humidity ≤90％RH
Dimensions 170.2mm×150.2mm×34.3mm
INTERNET port is connected with internet line, LOCAL port is used for
ordinary equipment.
When the nexhome app adds the gateway, click the wireless switch
to turn on the wireless signal, long press 5S to turn off the wireless
signal.
Press ZigBee switch 5S to allow the device to access the network.
Management: http://002396.net Or http://192.168.10.1
Password: 002396
SSID：SmartControl_ XXXXXX
Wireless password: 002396ap
[note] "XXXXXX" is the last 6 digits of MAC address, The MAC address
can be found on the back label of the devices.
