User's Manual

Solar Bluetooth GPS Receiver User Manual

-4-

Bluetooth GPS receiver outdoor or open sky at least 15~20 minutes for sure 3D

position fixed and almanac updated.

1. Introduction

Solar Bluetooth GPS Receiver is a total solution of GPS receiver. High capacity rechargeable

lithium-ion battery and solar charger circuit build-in, GPS antenna, Blue tooth transmit/receive

system are included. It is designed on the most advantage GPS kernel(FirstGPS

), got the

full-function, industry-level locating capacity and low prices.

You can use Solar Bluetooth GPS Receiver as vehicles navigator, security system,

geographic measurement, investigations or agriculture purpose. Solar Bluetooth GPS Receiver

operation requirement is a proper power supply and the open sky-view. Solar Bluetooth GPS

Receiver can communicate with other electronic devices by Blue tooth interface. Built-In Flash

Memory can save satellite information and do almanac refresh periodically .This will shorten

Time To First Fix(TTFF) effectively.

Patent protected Solar Cell design can extend the device usage time up to 30 hrs. This is much

longer than competitors’. Lithium-ion battery can be re-charged reasonably under nature or

artificial sunlight no matter Solar7 receiver is turned on or off. Most of time ,you are free of

charger!

Solar Bluetooth GPS Receiver is designed as a ultra low power consumption device, and

high position accuracy. It will update the satellite position every second. The Solar Bluetooth GPS

Receiver auto-locating feature is capable of automatically determining a navigation solution

without intervention. However, acquisition performance could be interfered and do cold start if the

receiver were initialized with occurrence of the following events:

1) First in use

2 )The GPS receiver is not in use for more than 3 months or transportation over distances

further than 500 kilometers.

3) Failure of the internal memory battery without system standby power.

2. Features and Functions

1),Total solution in power management.

Unique Solar Cell re-charging design (patent protected) can extend your GPS operation up to 30

hrs .

2)Green solution in exactly wireless GPS receiver application

Always charge your lithium-ion battery under nature or artificial sunlight.

Spare your charger, Spare your space

3) Considerate LED/switch button design

easy look, easy touch !one-touch button design keep your hand free

4)Act as WARM/HOT start with built-in battery

back-up power design will keep flash memory and RTC clocking always.
