AddingFrSkytoaSpektrumDX8
11
3. FittheDHTindicatorboardinsidethebacknexttotheAuxknobpotandasfar
forwardaspossible.MarkthepositionoftheLED,measurethedistanceanddrilla
3mmholeforitfromtheoutside.Checkitisintherightplacethendrilla3.5mm
holeforthebindbuttonatthecorrectspacing.Drilla6.5mmholefortheaerial
connectornexttotheTrainerswitch.SeeThreeHoles*.TheDHTbindboardshould
beheldsolidlyinthecasebytheLEDthroughtheholeandsomehotglue.Check
thatthebindbutton
justprotrudesenoughandthatitswitcheswithoutcatching on
thecase.
4. MakeaholeorcutoutforthepowerswitchnexttotheTrainerJack.
SeePowerSwitchCutout*.Adrilledholeforatoggleswitchisaloteasier.Fastenin
thepowerswitch(epoxyisgood
foraslideswitch)andcuttheredwireofthenew
powerwireandsoldertotheswitch.Iwoundtheexcessblackwireroundthe
unusedthirdterminaljusttohelpanchorthewire.SeePowerSwitchWiring*.Itends
uplookinglikePowerSwitch*.
