Preparation
Before beginning the installation:
1. Check that the concrete pad is level and cured.
2. Verify that the service wiring, circuit protection, and metering complies with local codes/regulations and
is ready per the Boost Charger Site Preparation Guide (Part Number 770-00004-01)
3. Ensure the grounding conductor is properly grounded and complies with local codes.
4. Confirm there is a strong cellular signal available. The Boost Charger requires a cellular network. Install
repeaters if the signal is below -110 dBm or if the signal is intermittent. A hard-wired internet connection
can be used if there’s no cellular signal available.
5. Check to make sure that the area is safely marked off and has enough space available for tooling,
shipping crates, lifting equipment, and work trucks.
6. Confirm that all parts, tools, and equipment are available.
7. Become familiar with the entire Boost Charger installation process.
Important: In geographic areas that experience frequent thunderstorms, a supplemental surge
protection breaker must be installed at the service panel.
Boost Charger Shipping Crates
The FreeWire Boost Charger ships in one crate. The Boost Charger Mounting Template ships separately.
Caution: Transport and store the FreeWire Boost Charger in its original packaging. A forklift or
crane must be used when handling the equipment. Ensure proper load rating of equipment before
beginning.
Caution: When using a crane, make sure that the straps and cables are rated for the weight of the
Boost Charger and crates.
Approximate Dimensions Approximate Crated Weight Contents
65” x 46.5” x 102” 4,100 lbs Boost Charger
48” x 40” x 20” 100 lbs Mounting Template
