Full Product Manual

MODEL: P800AJS
HTTP://WWW.FREEMANTOOLS.COM 1-888-669-567210
MODEL: P800AJS
HTTP://WWW.FREEMANTOOLS.COM 1-888-669-5672 11
CHARGING OTHER DEVICE
1.
The car jumper also has 15V/10A output. Check
the device’s voltage and current output rating
before using.
CHARGING A PHONE, TABLET, OR
OTHER USB DEVICES
1.
Plug the USB cable into the USB output on the
jump starter. Then insert charging cable into the
device that needs to be charged. Press the power
button on your jump starter and the device will
begin to charge.
Boost Button
Reverse Light
Correct Light
4.
Start the car engine. If after 3 seconds engine does
not start, turn key to “OFF” position. Detach the car
jumper clamps, then restart steps 1-4.
on the engine.
NO LIGHTS ON AND NO BUZZING:
The battery may be to low. Make sure the clamps
are connected correctly, press the “BOOST” button
and wait for the GREEN LIGHT to come on. If the
light does come on, turn on the engine within 30s.
If the light does not come on, take the vehicle to a
certified mechanic or consult the owner’s manual.
5.
Unplug the cable plug from the jump starter.
6.
Remove the clamps from the battery terminals.
1.
CHARGING THE CAR JUMPER
Plug wall charger/car charger cable into the wall/
car input. Then plug the cable into the input port of
the car jumper. The light indicator should start to
blink while the jumper is being charged.
