Full Product Manual

MODEL: P800AJS
HTTP://WWW.FREEMANTOOLS.COM 1-888-669-567208
MODEL: P800AJS
HTTP://WWW.FREEMANTOOLS.COM 1-888-669-5672 09
2.
3. Check the lights on the smart safety connector.
GREEN LIGHT ON:
The clamps are placed in the correct position and
the circuit is completed. Jump start the vehicle
within 30 seconds.
GREEN LIGHT BLINKING WITH BUZZING:
The vehicle battery is low. Press the “BOOST”
button, wait until the GREEN LIGHT becomes
solid, then turn on the engine within 30s.
RED LIGHT ON WITH BUZZING:
The clamps are clamped on to the incorrect
terminals. Reconnect the clamps to the correct
terminals, wait till the GREEN LIGHT is on, then
turn
Make sure the vehicle key is in the “OFF” position.
For push-to-start vehicles, make sure the vehicle is
in completely "OFF" before jump starting. Then
locate the positive and negative battery terminals.
The positive is normally labeled with a (+) and/or
red coloring. Connect the red clamp to the positive
Red
Black
PRODUCT LAYOUT
1.
Insert the smart safety connector plug into the jump
starter. The jump starter should automatically
power on. If it does not, press the power button on
the jump starter.
Jump Start Socket
Indicator
Power Button
LED Flash Light
Quick Charge
Output Port
15V/10A output port
Quick Charge input port
OPERATION
JUMPING A CAR
terminal and the black clamp to the negative
terminal of the vehicle battery.
