Installation Instructions

TRANSITIONINSTALLATION
WATERPROOF
T-MOLDING
V-T-14
Used to fill the gap between two
floors of equal height.
Used with floors ranging from
2-6mm in height.
Surface: Wear resistant
Core Material: Rigid PVC
Dimension: 1.77˝w x 0.28”h
0.514˝
Measure and trim to fit.
Suboor Suboor
Suboor Suboor
Floor
Floor
Floor
Floor
1
/
4
˝
1
/
4
˝
Install the flooring leaving a 1-1/8” gap between
the two floors for the t-molding installation.
Suboor
1
1
/8
˝
FloorFloor
Center the track between the flooring leaving a
1/4” spacing between the track and floor planks.
Screw track to subfloor using included screws
(or glue down with construction adhesive).
Starting at one end, press the molding into the
track inching along the length of the molding.
It will NOT snap in all at once. You may also use a rubber mallet.
