- 641 -
Clear Log - Remove all log information.
11.2.5.6 Configuring Hosts configuration Page
Selection Criteria
Host - This is a list of the hosts that have been configured for syslog. Select a host for changing the
configuration or choose to add a new hosts from the drop down list.
Severity Filter -A log records messages equal to or above a configured severity threshold. Select the
severity option by selecting the corresponding line on the pulldown entry field. These severity levels
have been enumerated below:
− Emergency (0): system is unusable
− Alert (1): action must be taken immediately
− Critical (2): critical conditions
− Error (3): error conditions
− Warning (4): warning conditions
− Notice(5): normal but significant conditions
− Informational(6): informational messages
− Debug(7): debug-level messages
Configurable Data
IP Address - This is the ip address of the host configured for syslog.
Port -This is the port on the host to which syslog messages are sent. The default port is 514. Specify
the port in the text field.
Non-Configurable Data
Status -This specifies wether the host has been configured to be actively logging or not.
Command Buttons
Submit - Update the switch with the values you entered.
Refresh - Refetch the database and display it again starting with the first entry in the table.
Delete - Delete a configured host.
