Boot Rom Version - The release-version number of the boot rom code currently running on the
switch. For example, if the release was 1, and the version was 2, the format would be '1.2'.
Label Revision Number - The label revision serial number of this switch is used for manufacturing
purpose.
Runtime Version - The release-version number of the code currently running on the switch. For
example, if the release was 1, and the version was 2, the format would be '1.2..
Operating System - The operating system currently running on the switch.
Network Processing Device - Identifies the network processor hardware.
ADT7460_1: Now Temperature: The temperature of sensor of ADT7460 1.
ADT7460_2: Now Temperature: The temperature of sensor of ADT7460 2.
Depend on air flow FAN 1 – 4 connected ADT7460-1 or ADT7460-2:
Front-To-Back: (Connected ADT7460-1)
ADT7460_1: Fan 1 Status: Status of Fan1. It could be active or inactive.
ADT7460_1: Fan 2 Status: Status of Fan2. It could be active or inactive.
ADT7460_1: Fan 3 Status: Status of Fan3. It could be active or inactive.
ADT7460_1: Fan 4 Status: Status of Fan3. It could be active or inactive.
Back-To-Front: (Connected ADT7460-2)
ADT7460_2: Fan 1 Status: Status of Fan1. It could be active or inactive.
ADT7460_2: Fan 2 Status: Status of Fan2. It could be active or inactive.
ADT7460_2: Fan 3 Status: Status of Fan3. It could be active or inactive.
ADT7460_2: Fan 4 Status: Status of Fan3. It could be active or inactive.
Switch Power+ y……………… Power Supply (The yth power supply information of switch 1).
Name: Name provided by Power Supply vendor.
Model: Model Number provided by Power Supply vendor.
Revision Number: Revision Number provided by Power Supply vendor.
Manufacturer Location: Location provided by Power Supply vendor.
Date of Manufacturing: Date of Manufacturing provided by Power Supply vendor.
Serial Numbe: Serial Number provided by Power Supply vendor.
Temperature 1:. Inner temperature 1 of Power Supply now
Temperature 2: Inner temperature 2 of Power Supply now
Fan Speed: Inner fan speed(rpm) of Power Supply now
Fan Duty: Inner fan duty(%) of Power Supply now
!
Below 10-Giga Interface information depend on plugging SFP+ Transceiver
