10.4.2.32 exit-overflow-interval
This command configures the exit overflow interval for OSPF. It describes the number of seconds after
entering Overflow state that a router will wait before attempting to leave the Overflow State. This allows
the router to again originate non-default AS-external-LSAs. When set to 0, the router will not leave
Overflow State until restarted.
Syntax
exit-overflow-interval <0-2147483647>
no exit-overflow-interval
<0-2147483674> - The range of exit overflow interval for OSPF is 0 to 2147483674.
no - This command configures the default exit overflow interval for OSPF.
Default Setting
0
Command Mode
Router OSPFv3 Config
10.4.2.33 external-lsdb-limit
This command configures the external LSDB limit for OSPF. If the value is -1, then there is no limit. When
the number of non-default AS-external-LSAs in a router's link-state database reaches the external LSDB
limit, the router enters overflow state. The router never holds more than the external LSDB limit
non-default AS-external-LSAs in it database. The external LSDB limit MUST be set identically in all
routers attached to the OSPF backbone and/or any regular OSPF area.
Syntax
external-lsdb-limit <-1-2147483647>
no external-lsdb-limit
<-1-2147483647> - The range of external LSDB limit for OSPF is -1 to 2147483674.
no - This command configures the default external LSDB limit for OSPF.
Default Setting
-1
Command Mode
Router OSPFv3 Config
