10.4.2.5 ipv6 ospf hello-interval
This command sets the OSPF hello interval for the specified interface. The value for <seconds> is a valid
positive integer, which represents the length of time in seconds. The value for the length of time must be
the same for all routers attached to a network. Valid values for <seconds> range from 1 to 65535.
Syntax
ipv6 ospf hello-interval <seconds>
no ipv6 ospf hello-interval
<no> - This command sets the default OSPF hello interval for the specified interface.
Default Setting
10
Command Mode
Interface Config
10.4.2.6 ipv6 ospf mtu-ignore
This command disables OSPF maximum transmission unit (MTU) mismatch detection. OSPF Database
Description packets specify the size of the largest IP packet that can be sent without fragmentation on the
interface. When a router receives a Database Description packet, it examines the MTU advertised by the
neighbor. By default, if the MTU is larger than the router can accept, the Database Description packet is
rejected and the OSPF adjacency is not established.
Syntax
ipv6 ospf mtu-ignore
no ipv6 ospf mtu-ignore
<no> - This command enables the OSPF MTU mismatch detection.
Default Setting
Enabled
Command Mode
Interface Config
10.4.2.7 ipv6 ospf network
This command changes the default OSPF network type for the interface. Normally, the network type is
determined from the physical IP network type. By default all Ethernet networks are OSPF type broadcast.
Similarly, tunnel interfaces default to point-to-point. When an Ethernet port is used as a single large
