7.2.2.2 show mac-addr-table count
This command displays the total forwarding database entries, the number of static and learnning mac
address, and the max address available on the switch.
Syntax
show mac-addr-table count
Default Setting
None
Command Mode
Privileged Exec
Display Message
Dynamic Address count: The total learning mac addresses on the L2 MAC address Table.
Static Address (User-defined) count: The total user-defined addresses on the L2 MAC address
Table.
Total MAC Addresses in use: This number of addresses are used on the L2 MAC address table.
Total MAC Addresses available: The switch supports max value on the L2 MAC address table.
7.2.2.3 show mac-addr-table interface
This command displays the forwarding database entries. The user can search FDB table by using
interface number <slot/port>.
Syntax
show mac-addr-table interface <slot/port>
<slot/port> - Interface number.
Default Setting
None
Command Mode
Privileged Exec
Display Message
Mac Address: A unicast MAC address for which the switch has forwarding and/or filtering
information. The format is 6 or 8 two-digit hexadecimal numbers that are separated by colons, for
example 01:23:45:67:89:AB. In an IVL system the MAC address will be displayed as 8 bytes. In an
SVL system, the MAC address will be displayed as 6 bytes. Note: This software version only
supports IVL systems.
VLAN ID: The vlan id of that mac address.
Status: The status of this entry.
The meanings of the values are:
