- 569 -
External Routing: Is a number representing the external routing capabilities for this area.
Spf Runs: Is the number of times that the intra-area route table has been calculated using this area's
link-state database.
Area Border Router Count: The total number of area border routers reachable within this area.
Area LSA Count: Total number of link-state advertisements in this area's link-state database,
excluding AS External LSAs.
Area LSA Checksum: A number representing the Area LSA Checksum for the specified AreaID
excluding the external (LS type 5) link-state advertisements.
Stub Mode: Represents whether the specified Area is a stub area or not. The possible values are
enabled and disabled. This is a configured value.
Import Summary LSAs: Shows whether to import summary LSAs (enabled).
OSPF Stub Metric Value: Shows the metric value of the stub area. This field displays only if the area
is a configured as a stub area.
The following OSPF NSSA specific information displays only if the area is configured as an
NSSA.
Import Summary LSAs: Shows whether to import summary LSAs into the NSSA.
Redistribute into NSSA: Shows whether to redistribute information into the NSSA.
Default Information Originate: Shows whether to advertise a default route into the NSSA
Default Metric: Shows the metric value for the default route advertised into the NSSA.
Default Metric Type: Shows the metric type for the default route advertised into the NSSA.
Translator Role Shows the NSSA translator role of the ABR, which is always or candidate.
Translator Stability Interval: Shows the amount of time that an elected translator continues to
perform its duties after it determines that its translator status has been deposed by another router.
Translator State: Shows whether the ABR translator state is disabled, always, or elected.
10.4.1.4 show ipv6 ospf asbr
This command displays the internal OSPFv3 routes to reach Autonomous System Boundary Routers
(ASBR). This command takes no options.
Syntax
show ipv6 ospf asbr
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Messages
