- 568 -
10.4.1.2 show ip ospf abr
This command displays the internal OSPFv3 routes to reach Area Border Routers (ABR).This command
takes no options.
Syntax
show ipv6 ospf abr
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Messages
Type: The type of the route to the destination. It can be either:
• intra — Intra-area route
• inter — Inter-area route
Router ID: Router ID of the destination
Cost: Cost of using this route
Area ID: The area ID of the area from which this route is learned.
Next Hop: Next hop toward the destination
Next Hop Intf: The outgoing router interface to use when forwarding traffic to the next hop.
10.4.1.3 show ipv6 ospf area
This command displays information about the area. The <areaid> identifies the OSPF area that is being
displayed.
Syntax
show ipv6 ospf area <areaid>
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Messages
AreaID: Is the area id of the requested OSPF area.
