- 535 -
9.7.1.4 show ip igmp-proxy interface
This command displays a detailed list of the host interface status parameters. It displays the following
parameters only when you enable IGMP Proxy.
Syntax
show ip igmp-proxy interface
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
Interface Index: Shows the slot/port of the IGMP proxy.
The column headings of the table associated with the interface are as follows:
Ver: Shows the IGMP version.
Query Rcvd: Number of IGMP queries received.
Report Rcvd: Number of IGMP reports received.
Report Sent: Number of IGMP reports sent.
Leaves Rcvd: Number of IGMP leaves received.
Leaves Sent: Number of IGMP leaves sent.
9.7.2 Configuration Commands
9.7.2.1 ip igmp-proxy
This command enables the IGMP Proxy on the router. To enable the IGMP Proxy on the router, you must
enable multicast forwarding. Also, make sure that there are no multicast routing protocols enabled on the
router.
Syntax
ip igmp-proxy
no ip igmp-proxy
no - This command disables the IGMP Proxy on the router.
