9.6.2.7 ip pimsm hello-interval
This command configures the transmission frequency of hello messages in seconds between PIM
enabled neighbors. This field has a range of 0 to 18000 seconds.
Syntax
ip pimsm query-interval <0 - 18000>
no ip pimsm query-interval
<0 - 18000> - This is time interval in seconds.
no - This command resets the transmission frequency of hello messages between PIM enabled
neighbors to the default value.
Default Setting
30
Command Mode
Interface Config
9.6.2.8 ip pimsm bsr-border
This command is used to prevent bootstrap router (BSR) messages from being sent or received through
an interface.
Syntax
ip pimsm bsr-border
no ip pimsm bsr-border
no - This command is used to disable the interface from being the BSR border.
Default Setting
Disabled
Command Mode
Interface Config
9.6.2.9 ip pimsm dr-priority
This command is used to set the priority value for which a router is elected as the designated router (DR).
Syntax
