- 510 -
Queries Received: The number of valid MLD queries received by the router.
Queries Sent: The number of valid MLD queries sent by the router.
Reports Received: The number of valid MLD reports received by the router.
Reports Sent: The number of valid MLD reports sent by the router.
Leaves Received: The number of valid MLD leaves received by the router.
Leaves Sent: The number of valid MLD leaves sent by the router.
Bad Checksum MLD Packets: The number of bad checksum MLD packets received by the router.
Malformed MLD Packets: The number of malformed MLD packets received by the router.
9.3.2 Configuration Commands
9.3.2.1 ipv6 mld query-interval
Use this command to set the MLD router’s query interval for the interface. The query-interval is the
amount of time between the general queries sent when the router is the querier on that interface. The
range for <query-interval> is 1 to 3600 seconds.
Syntax
ipv6 mld query-interval <1-3600>
no ipv6 mld query-interval
no – Use this command to reset the MLD query interval to the default value for that interface.
Default Setting
125
Command Mode
Interface Config
9.3.2.2 ipv6 mld query-max-response-time
Use this command to set the MLD querier’s maximum response time for the interface and this value is
used in assigning the maximum response time in the query messages that are sent on that interface. The
range for <query-max-responsetime> is 0 to 65535 milliseconds.
Syntax
ipv6 mld query-max-response-time <1-65535>
no ipv6 mld query-max-response-time
no - This command resets the MLD query max response time for the interface to the default value.
