- 471 -
8.4.2.5 bootpdhcprelay serverip
This command configures the server IP Address for BootP/DHCP Relay on the system.
Syntax
bootpdhcprelay serverip <ipaddr>
no bootpdhcprelay serverip
<ipaddr> - The IP address of the BootP/DHCP server.
no - Clear the IP address of the BootP/DHCP server.
Default Setting
None
Command Mode
Global Config
8.5 Routing Information Protocol (RIP) Commands
8.5.1 Show Commands
8.5.1.1 show ip rip
This command displays information relevant to the RIP router.
Syntax
show ip rip
Default Setting
None
Command Mode
Privileged Exec
Display Message
RIP Admin Mode: Select enable or disable from the pulldown menu. If you select enable RIP will be
enabled for the switch. The default is disabled.
Split Horizon Mode: Select none, simple or poison reverse from the pulldown menu. Split horizon is
a technique for avoiding problems caused by including routes in updates sent to the router from which
the route was originally learned. The options are: None - no special processing for this case. Simple -
a route will not be included in updates sent to the router from which it was learned. Poisoned reverse
