Type: Is the type that was configured into the unit. The possible values are Local, Gateway, Dynamic
and Static.
Age: This field displays the current age of the ARP entry since last refresh (in hh:mm:ss format).
8.1.1.2 show ip arp brief
This command displays the brief Address Resolution Protocol (ARP) table information.
Syntax
show ip arp brief
Default Setting
None
Command Mode
Privileged Exec
Display Message
Age Time: Is the time it takes for an ARP entry to age out. This value was configured into the unit.
Age time is measured in seconds.
Response Time: Is the time it takes for an ARP request timeout. This value was configured into the
unit. Response time is measured in seconds.
Retries: Is the maximum number of times an ARP request is retried. This value was configured into
the unit.
Cache Size: Is the maximum number of entries in the ARP table. This value was configured into the
unit.
Dynamic renew mode: Displays whether the ARP component automatically attempts to renew
dynamic ARP entries when they aged out.
Total Entry Count Current/Peak: Field listing the total entries in the ARP table and the peak entry
count in the ARP table.
Static Entry Count Configured/Active/Max: Field listing the configured static entry count, active
static entry count, and maximum static entry count in the ARP table.
8.1.1.3 show ip arp static
This command displays the static Address Resolution Protocol (ARP) table information.
Syntax
show ip arp static
Default Setting
