- 402 -
7.24.1.2 show queue ip-dscp-mapping
This command maps an IP DSCP value to an internal traffic class. The <ipdscp> value is specified as
either an integer from 0 to 63, or symbolically through one of the following keywords: af11, af12, af13,
af21, af22, af23, af31, af32, af33, af41, af42, af43, be, cs0, cs1, cs2, cs3, cs4, cs5, cs6, cs7, ef.
The <trafficclass> values can range from 0-6, although the actual number of available traffic classes
depends on the platform.
Syntax
show queue ip-dscp-mapping
Default Setting
None
Command Mode
Privileged EXEC
Display Message
IP DSCP: Displays IP DSCP value.
Traffic Class: Displays the queue mapping.
7.24.1.3 show queue trust
This command displays the current trust mode setting for a specific interface. The slot/port parameter is
optional and is only valid on platforms that support independent per-port class of service mappings. If
specified, the port trust mode of the interface is displayed. If omitted, the port trust mode of each interface
in the system is shown. If the platform does not support independent per-port class of service mappings,
the output represents the system-wide port trust mode used for all interfaces.
Syntax
show queue trust <slot/port>
< slot/port > The interface number.
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
Class of Service Trust Mode: The trust mode of this interface.
