- 382 -
Command Mode
Global Config (for all system interfaces)
Interface Config (for a specific interface)
Restrictions Only a single policy may be attached to a particular interface in a particular direction at
any one time.
7.21.4.2 no service-policy
This command detaches a policy from an interface in a particular direction.
Syntax
no service-policy in <policy-map-name>
The command can be used in the Interface Config mode to detach a policy from a specific interface.
Alternatively, the command can be used in the Global Config mode to detach this policy from all system
interfaces to which it is currently attached. The direction value is either in or out.
<policy-map-name> - is the name of an existing DiffServ policy. Note that this command causes a
service to remove its reference to the policy.
i
This command effectively disables DiffServ on an interface (in a particular direction).There is
no separate interface administrative 'mode' command for DiffServ.
Command Mode
Global Config (for all system interfaces)
Interface Config (for a specific interface)
7.21.5 Show Commands
The 'show' command set is used in DiffServ to display configuration and status information for:
• Classes
• Policies
• Services
