- 380 -
<set-cos-transmit> - an priority value is required and is specified as an integer from 0-7.
<set-dscp-transmit> - is required and is specified as either an integer from 0 to 63, or symbolically
through one of the following keywords: af11, af12, af13, af21, af22, af23, af31, af32, af33, af41,
af42, af43, be, cs0, cs1, cs2, cs3, cs4, cs5, cs6, cs7, ef.
<set-prec-transmit> - an IP Precedence value is required and is specified as an integer from 0-7.
Command Mode
Policy-Class-Map Config
Incompatibilities
Drop, Mark(all forms)
7.21.3.12 policy-map
This command establishes a new DiffServ policy. The <policyname> parameter is a case-sensitive
alphanumeric string from 1 to 31 characters uniquely identifying the policy. The type of policy is specific to
the inbound traffic direction as indicated by the in parameter.
Syntax
policy-map <policyname> [ in ]
no policy-map <policyname>
Command Mode
Global Config
Policy Type
In
7.21.3.13 policy-map rename
This command changes the name of a DiffServ policy. The <policyname> is the name of an existing
DiffServ class. The <newpolicyname> parameter is a case-sensitive alphanumeric string from 1 to 31
characters uniquely identifying the policy.
Syntax
policy-map rename <policyname> <newpolicyname>
<policyname> - Old Policy name.
<newpolicyname> - New policy name.
Command Mode
