- 372 -
Syntax
match srcl4port {<portkey> | <0-65535>}
<portkey> is one of the supported port name keywords (listed below).
The currently supported <portkey> values are: domain, echo, ftp, ftpdata, http, smtp, snmp, telnet,
tftp, www. Each of these translates into its equivalent port number, which is used as both the start and
end of a port range.
To specify the match condition as a numeric value, one layer 4 port number is required. The port number
is an integer from 0 to 65535.
To specify the match condition as a range, two layer 4 port numbers are required and together they
specify a contiguous port range. Each port number is an integer from 0 to 65535, but with the added
requirement that the second number be equal to or greater than the first.
Default Setting
None
Command Mode
Class-Map Config / IPv6-Class-Map Config
7.21.2.19 match vlan
This command adds to the specified class definition a match condition based on the value of the layer 2
VLAN Identifier field (the only tag in a single tagged packet or the first or outer tag of a double VLAN
tagged packet). The VLAN ID is an integer from 1 to 4095.
i
This command is not available on the Broadcom 5630x platform.
Syntax
match vlan <1-4095>
Default Setting
None
Command Mode
Class-Map Config
