User manual
Table Of Contents
- Introduction
- Product Overview
- Installation and Quick Startup
- Package Contents
- Switch Installation
- Installing the Switch in a Rack
- Quick Starting the Switch
- System Information Setup
- Quick Start up Software Version Information
- Quick Start up Physical Port Data
- Quick Start up User Account Management
- Quick Start up IP Address
- Quick Start up Uploading from Switch to Out-of-Band PC
- Quick Start up Downloading from Out-of-Band PC to Switch
- Quick Start up Downloading from TFTP Server
- Quick Start up Factory Defaults
- Console and Telnet Administration Interface
- Web-Based Management Interface
- Command Line Interface Structure and Mode-based CLI
- Switching Commands
- System Information and Statistics commands
- Device Configuration Commands
- Interface
- L2 MAC Address and Multicast Forwarding Database Tables
- VLAN Management
- Double VLAN commands
- GVRP and Bridge Extension
- IGMP Snooping
- IGMP Snooping Querier
- MLD Snooping
- MLD Snooping Querier
- Port Channel
- Storm Control
- L2 Priority
- Port Mirror
- Link State
- Port Backup
- FIP Snooping
- Enhanced Transmission Selection (ETS)
- Congestion Notification
- Management Commands
- Spanning Tree Commands
- System Log Management Commands
- Script Management Commands
- User Account Management Commands
- Security Commands
- CDP (Cisco Discovery Protocol) Commands
- SNTP (Simple Network Time Protocol) Commands
- MAC-Based Voice VLAN Commands
- LLDP (Link Layer Discovery Protocol) Commands
- Denial Of Service Commands
- VTP (VLAN Trunking Protocol) Commands
- Protected Ports Commands
- Static MAC Filtering Commands
- System Utilities
- DHCP Snooping Commands
- IP Source Guard (IPSG) Commands
- Dynamic ARP Inspection (DAI) Command
- Differentiated Service Command
- ACL Command
- IPv6 ACL Command
- CoS (Class of Service) Command
- Domain Name Server Relay Commands
- Routing Commands
- IP Multicast Commands
- IPv6 Commands
- Web-Based Management Interface
- Overview
- System Menu
- View ARP Cache
- Viewing Inventory Information
- Configuring Management Session and Network Parameters
- Defining Forwarding Database
- Viewing Logs
- Managing Switch Interface
- Defining sFlow
- Defining SNMP
- Viewing Statistics
- Managing System Utilities
- Managing CDP Function
- Defining Trap Manager
- Configuring SNTP
- Defining DHCP Client
- Defining DNS Relay Function
- Switching Menu
- Managing DHCP Snooping
- Managing IP Source Guard (IPSG)
- Managing Dynamic ARP Inspection (DAI)
- Managing Filters
- Managing Port-based VLAN
- Managing Protected Ports
- Managing Protocol-based VLAN
- Managing IP Subnet-based VLAN
- Managing MAC-based VLAN
- Managing MAC-based Voice VLAN
- Managing Voice VLAN
- Defining GARP
- Managing IGMP Snooping
- Managing IGMP Snooping Querier
- Managing MLD Snooping
- Managing MLD Snooping Querier
- Managing Port-Channel
- Viewing Multicast Forwarding Database
- Managing Spanning Tree
- Defining 802.1p priority
- Managing Port Security
- Managing LLDP
- Managing LLDP-MED
- Managing VTP
- Managing Link State
- Managing Port-Backup
- Managing FIP-Snooping
- Routing Menu
- Security Menu
- IPv6 Menu
- Configuring IPv6 Global Configuration Page
- Configuring IPv6 Interface Configuration Page
- Viewing IPv6 Interface Summary Page
- Viewing IPv6 Interface Statistics Page
- Viewing IPv6 Neighbor Table Information Page
- Viewing IPv6 Static Neighbor Table Information Page
- Managing OSPFv3 Protocol
- Managing IPv6 Routes
- Managing RIPv6
- QOS Menu
- IPv4 Multicast Menu
- IPv6 Multicast Menu
- 36 -
7.1.4 show eventlog
This command displays the event log, which contains error messages from the system, in the Primary
Management System or in the specified unit. The event log is not cleared on a system reset.
Syntax
show eventlog [unit]
unit - The unit number of the remote system. The range is 1 to 8.
Default Setting
None
Command Mode
Privileged Exec
Display Message
File: The file in which the event originated.
Line: The line number of the event.
Task Id: The task ID of the event.
Code: The event code.
Time: The time this event occurred.
Note: Event log information is retained across a switch reset.
7.1.5 show running-config
This command is used to display/capture the current setting of different protocol packages supported on
switch. This command displays/captures only commands with settings/configurations with values that
differ from the default value. The output is displayed in script format, which can be used to configure
another switch with the same configuration.
When a script name is provided, the output is redirected to a configuration script. The option [all] will also
enable the display/capture of all commands with settings/configurations that include values that are same
as the default values. If the optional <scriptname> is provided with a file name extension of “.scr”, the
output will be redirected to a script file.
Syntax
show running-config [all | <scriptname>]
all - enable the display/capture of all commands with settings/configurations that include values that
are same as the default values.
<scriptname> - redirect the output to the file <scriptname>.
