- 353 -
Syntax
ip verify binding <mac-address> vlan <vlan id> <ip address> interface <slot/port>
no ip verify binding <mac-address> vlan <vlan id> <ip address> interface <slot/port>
no - This command removes the IPSG static entry from the IPSG database.
Default Setting
None
Command Mode
Global Config
7.20 Dynamic ARP Inspection (DAI) Command
Dynamic ARP Inspection (DAI) is a security feature that rejects invalid and malicious ARP packets. DAI
prevents a class of man-in-the-middle attacks, where an unfriendly station intercepts traffic for other
stations by poisoning the ARP caches of its unsuspecting neighbors. The miscreant sends ARP requests
or responses mapping another station's IP address to its own MAC address.
To prevent ARP poisoning attacks, a switch must ensure that only valid ARP requests and responses are
relayed. DAI prevents these attacks by intercepting all ARP requests and responses. Each of these
intercepted packets is verified for valid MAC address to IP address bindings before the local ARP cache is
updated or the packet is forwarded to the appropriate destination. Invalid ARP packets are dropped.
DAI determines the validity of an ARP packet based on valid MAC address to IP address bindings stored
in a trusted database. This database is built at runtime by DHCP snooping, provided this feature is
enabled on VLANs and on the switch. DAI relies on DHCP snooping. DHCP snooping listens to DHCP
message exchanges and builds a binding database of valid {MAC address, IP address, VLAN, and
interface} tuples. In addition, in order to handle hosts that use statically configured IP addresses, DAI can
also validate ARP packets against user-configured ARP ACLs.
When DAI is enabled, the switch drops ARP packets whose sender MAC address and sender IP address
do not match an entry in the DHCP snooping bindings database. You can optionally configure additional
ARP packet validation.
7.20.1 Show Commands
7.20.1.1 show ip arp inspection statistics
This command displays the statistics of the ARP packets processed by Dynamic ARP Inspection. Give
the vlan-list argument and the command displays the statistics on all DAI-enabled VLANs in that list. Give
