7. Switching Commands
le
7.1 System Information and Statistics commands
7.1.1 show arp
This command displays connectivity between the switch and other devices. The Address Resolution
Protocol (ARP) cache identifies the MAC addresses of the IP stations communicating with the switch.
Syntax
show arp
Default Setting
None
Command Mode
Privileged Exec
Display Message
MAC Address: A unicast MAC address for which the switch has forwarding and/or filtering
information. The format is 6 two-digit hexadecimal numbers that are separated by colons. For
example: 00:23:45:67:89:AB
IP Address: The IP address assigned to each interface.
Interface: Valid slot number and a valid port number.
7.1.2 show calendar
This command displays the system time.
Syntax
show calendar
Default Setting
None
Command Mode
Privileged Exec
Display Message
Current Time displays system time
