- 270 -
CDP Holdtime (sec): The length of time a receiving device should hold the L2 Network Switch CDP
information before discarding it
CDP Transmit Interval (sec): A period of the L2 Network Switch to send CDP packet
Ports: Port number vs CDP status
CDP: CDP enable or disable
7.9.1.2 show cdp neighbors
This command displays the CDP neighbor information.
Syntax
show cdp neighbors
Default Setting
None
Command Mode
Privileged Exec
Display Message
Device Id: Identifies the device name in the form of a character string.
Local Interface: The CDP neighbor information receiving port.
Holdtime: The length of time a receiving device should hold CDP information before discarding it.
Capability: Describes the device's functional capability in the form of a device type, for example, a
switch.
Platform: Describes the hardware platform name of the device, for example, Fortinet the L2 Network
Switch.
Port Id: Identifies the port on which the CDP packet is sent.
7.9.1.3 show cdp neighbors detail
This command displays the CDP neighbor detail information.
Syntax
show cdp neighbors detail
Default Setting
None
Command Mode
