- 194 -
Display Message
Poller Data Source: The sFlowDataSource (slot/port) for this sFlow sampler. This agent will support
Physical ports only.
Receiver Index: The sFlowReceiver associated with this sFlow counter poller.
Poller Interval: The number of seconds between successive samples of the counters associated
with this data source.
7.3.13.3 show sflow receivers
The user can go to the CLI Privilege Exec to get the configuration information related to the sFlow
receivers, use the show sflow receivers Privilege command.
Syntax
show sflow receivers
Default Setting
None
Command Mode
Privilege Exec
Display Message
Receiver Index: The sFlow Receiver associated with the sampler/poller.
Owner String: The identity string for receiver, the entity making use of this sFlowRcvrTable entry.
Time Out: The time (in seconds) remaining before the receiver is released and stops sending
samples to sFlow receiver.
Max Datagram Size: The maximum number of bytes that can be sent in a single sFlow datagram.
Port: The destination Layer4 UDP port for sFlow datagrams.
IP Address: The sFlow receiver IP address.
7.3.13.4 show sflow samplers
The user can go to the CLI Privilege Exec to get the sFlow sampling instances created on the switch, use
the show sflow samplers Privilege command.
Syntax
show sflow samplers
Default Setting
None
